Gray 12.1 inch fanless all-in-one industrial panel PC with capacitive touch screen

partaker

partaker A26 12.1 inch AI edge system i5-8250U 32GB 512GB

SKU CH-FPHB-DBQNG

A fanless 12.1-inch industrial panel PC with IP65 front protection, Intel Core i5-8250U processor, 32 GB DDR4 memory, 512 GB storage, capacitive multi-touch screen, dual Gigabit LAN.

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 8th Gen
  • CPU NameIntel Core i5-8250U

A26 12.1" Capacitive I5 8250U 32GB RAM / 512GB SSD

  • Fanless aluminium alloy chassis enables silent operation in dusty industrial environments
  • IP65-rated front panel provides dust and water resistance for harsh conditions
  • Intel Core i5-8250U quad-core processor with up to 3.40 GHz delivers responsive multitasking performance
  • 32GB DDR4 memory and 512GB storage support demanding industrial applications
  • 1-inch capacitive touch screen with 1024x768 resolution offers clear multi-touch control

12.1-inch fanless industrial panel PC

The Partaker A26 is an all-in-one industrial computer built around a 12.1-inch capacitive multi-touch display with XGA resolution. It runs on an Intel Core i5-8250U quad-core processor with 32GB of DDR4 memory and a 512GB mSATA drive. The fanless aluminum alloy chassis carries an IP65-rated front panel for dust and water resistance. Windows 10 Pro comes pre-installed for immediate deployment in factory automation and edge AI tasks.

Sustained load behaviour

Passive cooling across the full metal chassis keeps the system silent while dissipating heat from the processor during continuous operation. The platform is rated for ambient temperatures from -20°C to 60°C with the solid-state drive installed, so performance remains stable in hot or cold production areas. Dual Gigabit Ethernet ports and dual configurable COM ports maintain reliable data links to PLCs, sensors and SCADA networks over long shifts. Watchdog timer support adds automatic recovery if a process stalls.

Upgrade path and fit

The A26 replaces older panel PCs that rely on active cooling and lack IP65 front protection, removing fan failure as a maintenance point. Its VESA and embedded mounting options fit existing cutouts of 298.5 by 237 millimetres without cabinet redesign. The jump is worthwhile when a project needs silent, dust-proof operation with modern I/O — dual LAN, HDMI, four USB ports and expandable Mini PCIe slots for wireless or cellular modules — on a 12V DC supply with an optional 9-36V wide-range input.

Helstu kostir

  • Fanless aluminium alloy chassis enables silent operation in dusty industrial environments
  • IP65-rated front panel provides dust and water resistance for harsh conditions
  • Intel Core i5-8250U quad-core processor with up to 3.40 GHz delivers responsive multitasking performance
  • 32GB DDR4 memory and 512GB storage support demanding industrial applications
  • 1-inch capacitive touch screen with 1024x768 resolution offers clear multi-touch control

Tæknilýsing

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 8th Gen
CPU NameIntel Core i5-8250U
Screen Size12.1"
Screen TypeMulti-Touch Screen

Aðrar útgáfur af þessari vöru

5 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

Does the fanless aluminium chassis stay quiet and cool when the i5-8250U runs at 3.40 GHz all day?

The fanless design means no moving parts, so operation is completely silent; the aluminium alloy shell dissipates heat passively and the unit is rated for continuous use from -20 °C to +60 °C with an SSD installed.

Which cables and mounts must I already have to install the 12.1-inch panel PC?

You need a 12 V DC power source (or the optional 9–36 V wide-range supply), a 298.5 mm × 237 mm cut-out for embedded mounting or a VESA bracket, and any network or serial cables for the dual Gigabit LAN and two RS232/485 COM ports.

Can the HDMI and LVDS outputs drive a legacy monitor alongside the built-in 1024×768 touch screen?

Yes, the HDMI port and the internal LVDS connection support synchronous or asynchronous dual-display operation, so an older external display can run at its native resolution while the 12.1-inch panel shows the same or different content.
