Three compact white desktop switches with five RJ45 ports each

Ubiquiti Networks

Ubiquiti Networks USW-Flex-Mini-3 3-pack 5-port network switch

SKU CH-DKH4-FHW7R MPN USW-Flex-Mini-3

A three-pack of compact, five-port managed Layer 2 switches with PoE power input and 5 Gbps non-blocking throughput

  • FormatDesktop
  • Network Management TypeManaged
  • Primary Ports5 x RJ45
  • Primary Port SpeedTotal non-blocking throughput 5 Gbps Switching capacity 10 G
  • PoEYes
  • Layer2

Model Flex Mini 3-Pack

Sjá 1 stillingar til viðbótar

Yfirstrikaðar útgáfur eru til, en ekki til hér.

  • Three switches in one pack for multi-room deployment
  • Five gigabit ports with 5 Gbps non-blocking throughput
  • PoE input port or USB-C adapter powers the unit
  • Layer 2 management with port isolation and storm control
  • Compact 107 x 70 x 21 mm desktop form factor

Three compact Layer 2 switches

This three-pack delivers three identical 5-port managed switches for small networks. Each unit fits on a desktop and draws power either from the single PoE input port or from the included 5V USB-C adapter. The fanless design runs silently in offices or home labs. Managed Layer 2 features give control over traffic without the complexity of Layer 3 routing.

Replaces unmanaged desktop switches

Moving up from a basic unmanaged switch adds port isolation, storm control, port mirroring and multicast rate limiting. The jump is worth it when you need to segment devices, prevent broadcast storms or mirror traffic for diagnostics. Builders who need Layer 3 routing, 10 GbE uplinks or SFP ports should look elsewhere. The 5 Gbps non-blocking throughput suits modest bandwidth needs.

Sustained traffic at wire speed

The 10 Gbps switching capacity and 7.44 Mpps forwarding rate handle continuous gigabit flows across all ports without head-of-line blocking. Operating temperature spans -5 to 45 °C, so the switch tolerates warm cabinets or outdoor enclosures. Humidity range of 10 to 90 % non-condensing supports damp environments. No moving parts means no fan wear during long-term deployment.

Helstu kostir

  • Three switches in one pack for multi-room deployment
  • Five gigabit ports with 5 Gbps non-blocking throughput
  • PoE input port or USB-C adapter powers the unit
  • Layer 2 management with port isolation and storm control
  • Compact 107 x 70 x 21 mm desktop form factor

Tæknilýsing

BrandUbiquiti Networks
SeriesNetwork Switch
ModelUSW-Flex-Mini
FormatDesktop
Network Management TypeManaged
Primary Ports5 x RJ45
Primary Port SpeedTotal non-blocking throughput 5 Gbps
Switching capacity 10 Gbps
Forwarding rate 7.44 Mpps
PoEYes
Layer2
Layer 2 FeaturesLayer 2 features Port isolation
Storm control
Port mirroring
Multicast / broadcast rate limiting
Flow control
Jumbo frames
Egress rate limit
LEDsSystem Status
Ethernet Speed/link/activity
Dimensions107 x 70 x 21 mm (4.2 x 2.8 x 0.8")
Weight150 g (5.3 oz)
Temperature-5 to 45° C (23 to 113° F)
Humidity10 to 90% noncondensing
Sendingarþyngd0.11 kg
Stærð sendingar102 × 102 × 102 mm

Aðrar útgáfur af þessari vöru

5 í viðbót í sama vöruflokki

Sama fjölskylda, mismunandi minni, kælingu eða klukkuhraða — berðu saman áður en þú ákveður þig.

Spurningar um þessa vöru

What are the exact dimensions of each USW-Flex-Mini switch so I can check if it fits my cabinet?

Each switch measures 107 x 70 x 21 mm (4.2 x 2.8 x 0.8") and weighs 150 g (5.3 oz), making it compact enough for tight desktop or wall-mounted spaces.

How do I power the Flex Mini switches and which port do I use for PoE input?

Connect the PoE source to the dedicated GbE PoE input port on each switch; alternatively, use the included 5V, 1A USB-C adapter (provided with single units) for non-PoE deployments.

What ongoing maintenance do the Fanless Flex Mini switches require after installation?

With no moving parts and an operating range of -5 to 45° C (23 to 113° F) at 10 to 90% noncondensing humidity, the switches need only occasional dust removal and cable checks.
