Aqua blue duplex fibre cable with LC and FC connectors, 3.0 mm jacket

Enfain

Enfain OM3 LC-FC Duplex Multimode Fibre Optic Cable Aqua Blue 3.0mm

SKU CH-84YB-94DFE

OM3 duplex multimode patch cord with LC and FC connectors, 3.0 mm jacket, 850 nm wavelength, 0.2 dB typical insertion loss, >38 dB return loss

Length 1m

  • Low-loss links with typical insertion loss of .2 dB
  • High signal integrity from return loss exceeding 38 dB
  • Reliable 10 Gb performance using OM3 850 nm multimode core
  • Durable 3.0 mm PVC jacket rated for 1000 mating cycles
  • Wide operating range from -20 °C to 60 °C for data-centre use

Enfain OM3 LC-FC Duplex Cable

The Enfain OM3 LC-FC duplex multimode fibre optic cable is built for 10-gigabit links between switches, servers and data-centre equipment. Its aqua blue 3.0 mm PVC jacket identifies the OM3 core at a glance. Installers who need a reliable short-range patch cord for 1 Gbit/s, 10 Gbit/s or 40 Gbit/s Ethernet will find the correct connectors and fibre grade in one assembly. Buyers who require single-mode reach or a different connector pairing cannot use this cable.

Build quality and daily handling

Ceramic ferrules on both ends deliver a typical insertion loss of .2 dB and a maximum of .3 dB, while return loss exceeds 38 dB for clean signal integrity. The 3.0 mm jacket tolerates a 330 mm bending radius, so routing through dense patch panels remains practical. Rated for 1000 mating cycles, the connectors withstand repeated moves during rack changes. The assembly operates from -20 °C to +60 °C, covering standard indoor environments.

Deciding specification

The OM3 10-gigabit multimode core operating at 850 nm is the single figure that determines compatibility; it supports 10 Gbit/s Ethernet over the distances defined by the OM3 standard. If the link budget or reach requires single-mode fibre or a higher-grade multimode core, this cable will not meet the requirement.

Priekšrocības

  • Low-loss links with typical insertion loss of .2 dB
  • High signal integrity from return loss exceeding 38 dB
  • Reliable 10 Gb performance using OM3 850 nm multimode core
  • Durable 3.0 mm PVC jacket rated for 1000 mating cycles
  • Wide operating range from -20 °C to 60 °C for data-centre use

Specifikācijas

Šai precei pagaidām nav publicētu specifikāciju.

Citas šī modeļa versijas

Vēl 5 šajā sērijā

Viena saime, taču atšķirīga atmiņa, dzesētājs vai frekvence — salīdziniet, pirms izlemjat.

Jautājumi par šo preci

What speeds does the OM3 duplex LC-FC cable support at the 850 nm wavelength?

The OM3 10-gigabit core is rated for 1G, 10G and 40G Ethernet links at 850 nm.

What is the minimum bend radius for the 3.0 mm PVC jacket?

The cable specifies a bending radius of 330 mm to avoid signal loss or fibre damage.

How do I clean the ceramic ferrules before mating the LC and FC connectors?

Use a lint-free wipe with isopropyl alcohol on each ferrule end-face, then inspect with a fibre scope before connecting.
