Black metal 1U rack strip with eight NEMA 5-15R outlets and a 15 ft cord

MINUTEMAN

MINUTEMAN OEPD815HV PDU 8-Outlet 120V 15A 15ft Cord

SKU CH-XD8G-8R761 MPN OEPD815HV

An eight-outlet 120 V rack PDU with a 15 ft cord and front-access receptacles for flexible 1U or 0U mounting

  • Rack Size1U
  • StyleHorizontal Installation, 0U Vertical Installation
  • Certifications62368-1 Certification
  • Maximum Input Current15A
  • Input Connector(s)NEMA 5-15P
  • Cord Length15 ft

Model OEPD815HV

Lihat 8 konfigurasi lagi

Versi yang dicoret wujud, tetapi tidak tersedia di sini.

  • 8 outlets distribute power to multiple devices
  • 15 ft cord reaches distant rack locations
  • Input circuit breaker protects connected equipment
  • Mounts horizontally in 1U or vertically in 0U
  • 62368-1 certified for safety compliance

OE Series 8-Outlet PDU

The Minuteman OEPD815HV is a rack-mountable power distribution unit that delivers 120 V AC through eight NEMA 5-15R receptacles. Two outlets sit on the front panel and six on the rear for convenient access. A 15 ft NEMA 5-15P input cord connects to standard facility power. The unit fits 1U horizontal or 0U vertical orientations.

Replaces basic power strips

This PDU upgrades a simple power strip by adding a built-in input circuit breaker for overload protection and a 15 ft cord that reaches distant rack sockets. The jump is worth it when equipment density requires both front and rear outlet access in a single 1U or 0U footprint. Buyers who need more than eight outlets should look at larger OE Series models.

Tool-less rack mounting

Horizontal 1U installation uses the included stand-off bracket; vertical 0U mounting uses the same bracket on compatible rack posts. The 15 ft cord eases routing to floor or overhead power sources. Common issues include exceeding the 15 A input rating when multiple high-draw devices are connected and forgetting to reset the circuit breaker after an overload event.

Ciri-ciri utama

  • 8 outlets distribute power to multiple devices
  • 15 ft cord reaches distant rack locations
  • Input circuit breaker protects connected equipment
  • Mounts horizontally in 1U or vertically in 0U
  • 62368-1 certified for safety compliance

Spesifikasi

BrandMINUTEMAN
SeriesOE Series
ModelOEPD815HV
Rack Size1U
StyleHorizontal Installation, 0U Vertical Installation
Certifications62368-1 Certification
Maximum Input Current15A
Input Connector(s)NEMA 5-15P
Cord Length15 ft
Output Connector(s)Front Panel Receptacles: (2) 5-15R
Rear Panel Receptacles: (6) 5-15R
Overload ProtectionInput Circuit Breaker Protection
FeaturesLonger power cords
Most Minuteman PDU units have up to 15-ft power cords, to allow for seamless installations
More standard outlets
Minuteman PDU units have 6, 8, 10, 14, 18, or 24 outlets. Most of the Minuteman PDUs have additional front outlets for improved access
Configuration versatility
Minuteman PDU units have a multi-form factor with 1U and 0U configurations allowing for either horizontal or vertical placement. 1U products ship with a stand-off mounting bracket, at no additional cost, that allows for vertical installation on most racks and enclosures
Locking (L) and Hardwire (
Berat penghantaran2.03 kg
Dimensi bungkusan432 × 89 × 44 mm

Versi lain model ini

5 lagi dalam julat yang sama

Keluarga yang sama, memori, penyejuk atau kelajuan jam yang berbeza — bandingkan sebelum membuat keputusan.

Soalan tentang produk ini

What rack space does the 1U OEPD815HV need for horizontal mounting?

The unit occupies 1U of rack height and ships with a stand-off bracket that also enables 0U vertical mounting on most racks.

How do you secure the PDU for vertical 0U installation?

Attach the included stand-off mounting bracket to the rack posts, then fasten the PDU to the bracket using the pre-drilled holes on its chassis.

Which component protects the eight NEMA 5-15R outlets from overload?

An input circuit breaker on the NEMA 5-15P plug side trips at 15 A; reset it after clearing the overload condition.
