15 inch industrial all-in-one PC with IP65 front panel and capacitive touchscreen

partaker

Partaker A4 15" all-in-one PC i7-8565U 8GB 256GB SSD 1TB HDD

SKU CH-3EJ6-B8QKY

A 15-inch industrial all-in-one PC with IP65 front protection, 10-point capacitive touchscreen, i7-8565U processor, 8GB DDR4, 256GB SSD and 1TB HDD

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 8th Gen
  • GPU/VGA TypeIntel UHD Graphics
  • Memory Capacity8GB DDR4
  • SSD256GB

Memory Capacity 8GB DDR4

SSD 256GB

  • 256GB
  • 512GB
  • 1TB

HDD 1TB

Versi yang dicoret wujud, tetapi tidak tersedia di sini.

  • IP65 front panel resists dust and water ingress
  • 10-point capacitive touchscreen enables precise multi-touch control
  • Intel Core i7-8565U up to 4.60 GHz handles continuous industrial workloads
  • Fanless aluminium alloy cooling runs silently with no moving parts
  • Windows 11 Pro pre-installed for immediate deployment

Industrial touch panel PC

The Partaker A4 is a 15-inch all-in-one system built around an Intel Core i7-8565U processor with 8GB of DDR4 memory, a 256GB SSD and a 1TB hard drive. Its front panel carries an IP65 rating and a 10-point projected capacitive touchscreen designed for continuous operation in factories, kiosks or outdoor enclosures. Windows 11 Pro comes pre-installed.

Fanless embedded mounting

The aluminium chassis uses passive cooling so there are no fans to fail or draw dust, but the unit must be installed with adequate airflow around its 54mm depth to stay within the 0–50°C operating range. Embedded panel cut-out dimensions are 348 by 272mm; the supplier recommends this method over wall or desktop mounting for best thermal results. A 12V DC supply is required and the watchdog timer can trigger automatic restart after a fault.

Legacy video and serial I/O

Video output is limited to HDMI and VGA ports, so modern DisplayPort or USB-C monitors need adapters. The board provides two USB 3.0 and two USB 2.0 ports, dual LAN, audio in/out and two COM ports for legacy industrial equipment. Expansion is via a single Mini PCIe slot with a SIM holder for optional 4G or Wi-Fi cards; there is no M.2 Key-E slot for newer wireless modules.

Ciri-ciri utama

  • IP65 front panel resists dust and water ingress
  • 10-point capacitive touchscreen enables precise multi-touch control
  • Intel Core i7-8565U up to 4.60 GHz handles continuous industrial workloads
  • Fanless aluminium alloy cooling runs silently with no moving parts
  • Windows 11 Pro pre-installed for immediate deployment

Spesifikasi

ModelA4-PA-150TPC-CE6A(I78)-8G256G1TB
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 8th Gen
GPU/VGA TypeIntel UHD Graphics
Memory Capacity8GB DDR4
SSD256GB
HDD1TB
Screen Size15"
TouchscreenYes

Versi lain model ini

5 lagi dalam julat yang sama

Keluarga yang sama, memori, penyejuk atau kelajuan jam yang berbeza — bandingkan sebelum membuat keputusan.

Soalan tentang produk ini

How can I verify the 10-point projected capacitive touchscreen is registering all touch points correctly after installation?

Open the Windows 11 Pro touch calibration tool and perform a multi-finger test; the screen supports up to 10 simultaneous points with a rated durability of 200 million touches.

Which items are included in the packing list and what must I source separately for a typical embedded installation?

The box contains the Partaker A4 panel PC, a 12 V power supply, a power cord and embedded mounting hardware; Wi-Fi or 4G modules for the Mini PCIe slot and a SIM card are not included.

Should I choose the 256 GB mSATA SSD or the 1 TB 2.5" HDD as the primary boot drive for an industrial environment?

Use the 256 GB mSATA SSD for the operating system; it allows the full 0–50 °C operating range, whereas the HDD limits the upper temperature to 40 °C.
