Rectangular black tower UPS with LCD screen and six NEMA 5-15R outlets

MINUTEMAN

MINUTEMAN EC1500LCD-NC 1500VA 1350W UPS

SKU CH-0X5X-043E9 MPN EC1500LCD-NC

Double-conversion online UPS delivers 1500VA/1350W with six NEMA 5-15R outlets and five minutes full-load runtime

  • International Version120V
  • Input Voltage Range0 V AC - 160 V AC
  • Input Frequency50/60Hz +/- 6Hz Auto-sensing
  • Input ConnectionNEMA 5-15P
  • VA Rating1500VA
  • Watts1350W

Model EC1500LCD-NC

Vis 7 flere konfigurasjoner
  • 1500 VA and 1350 W capacity keeps critical systems running during outages
  • Double-conversion online topology delivers clean, uninterrupted power to sensitive equipment
  • Six NEMA 5-15R outlets provide battery-backed and surge-protected connections
  • Replaceable sealed lead-acid battery (BM0077) extends service life without replacing the whole unit
  • Serial and RJ-45 ports enable remote monitoring and automated shutdown software

Product Identity

The Minuteman EC1500LCD-NC is a double-conversion online UPS rated at 1500VA and 1350W. It suits network equipment, servers or workstations that must stay online through voltage sags, surges or total loss of mains power.

Upgrade Context

It replaces a standby or line-interactive unit when the load cannot tolerate any transfer time or when output voltage must stay within .2Hz of nominal. The jump is worth it for critical data paths that would lose transactions or corrupt databases during even a brief switchover.

Interface Limits

Six NEMA 5-15R outlets share the 1350W capacity, so total connected draw must remain below that figure. Runtime at full load is 5 minutes and 15 minutes at half load, limiting the unit to orderly shutdown rather than extended operation. Recharge to 90 percent requires 8 hours.

Høydepunkter

  • 1500 VA and 1350 W capacity keeps critical systems running during outages
  • Double-conversion online topology delivers clean, uninterrupted power to sensitive equipment
  • Six NEMA 5-15R outlets provide battery-backed and surge-protected connections
  • Replaceable sealed lead-acid battery (BM0077) extends service life without replacing the whole unit
  • Serial and RJ-45 ports enable remote monitoring and automated shutdown software

Spesifikasjoner

BrandMINUTEMAN
ModelEC1500LCD-NC
International Version120V
Input Voltage Range0 V AC - 160 V AC
Input Frequency50/60Hz +/- 6Hz Auto-sensing
Input ConnectionNEMA 5-15P
VA Rating1500VA
Watts1350W
Output Voltage120VAC, User selectable: 110VAC, 127VAC
Output Frequency50/60Hz +/-0.2Hz unless synchronized to line
Outlets6
Outlet Type(6) NEMA 5-15R
Battery TypeSealed Lead Acid
Battery Run TimeHalf Load: 15 min
Full Load: 5 min
Battery Recharge Time8 hours to 90% from total discharge
Battery ReplaceableBM0077
Interface PortDB-9, RJ-45
ApprovalscULus (UL1778 5th Edition & CSA 22.2 no. 107.3-14 / R: 2014), FCC Class A, CE certified, RoHS2 (EU Directive 2011/65/EU & 2015/863/EU)
Surge Energy Rating254 Joules
TemperatureOperating Temperature +32 to +104°F (0 to 40°C)
Storage Temperature +14 to +122°F (-10 to +50°C)
Humidity10% to 90% non-condensing
Dimensions17.4" x 6.8" x 11.4"
Weight48.1 lbs.
Fraktvekt21.82 kg
Pakkestørrelse442 × 290 × 173 mm

Andre versjoner av denne modellen

5 flere i samme serie

Samme familie, annet minne, annen kjøler eller klokkefrekvens — sammenlign før du bestemmer deg.

Spørsmål om denne varen

What are the tower dimensions and weight for the MINUTEMAN EC1500LCD-NC?

The unit measures 17.4 inches deep by 6.8 inches wide by 11.4 inches high and weighs 48.1 pounds.

How is the UPS connected to a computer for monitoring, and what step is often missed?

Use the DB-9 serial or RJ-45 cable to link the interface port to your PC, then install the management software so automatic shutdown is configured.

Which battery kit replaces the sealed lead-acid cells when runtime drops?

Order the BM0077 replacement cartridge; recharge takes 8 hours to reach 90 percent after a full discharge.
