Silver 21.5 inch industrial panel PC with IP65 front, flat touchscreen, fanless aluminium chassis, embedded mounting buckles visible

partaker

Partaker A16-PA-215TPC-CE6A(I53) 21.5" IP65 Industrial Panel PC 8GB DDR3 256GB SSD

SKU CH-D8GF-VG13T

A 21.5" IP65-rated industrial panel PC with 10-point capacitive touch, Intel Core i5 3rd Gen at 1.70GHz, 8GB DDR3L and 256GB SSD

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 3rd Gen
  • CPU Name1.70GHz
  • GPU/VGA TypeIntel HD Graphics

GPU Intel HD Graphics

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 256GB

HDD None

Overstrøkne versjoner finnes, men er ikke på lager her.

  • IP65 front protection seals out dust and water jets
  • 10-point projected capacitive touch enables precise multi-finger input
  • Fanless aluminium alloy cooling runs silently with no moving parts
  • 12 V DC input suits industrial power infrastructure
  • 1920 x 1080 resolution on 21.5 inch TFT LED panel

Industrial Panel PC for 24/7 Operation

The Partaker A16-PA-215TPC-CE6A(I53) is a 21.5" all-in-one computer built for continuous industrial use. It runs on an Intel Core i5 3rd Gen processor at 1.70GHz with 8GB DDR3 memory and a 256GB SSD. The system ships with Windows 10 Pro installed for immediate deployment in factory automation, kiosk or machine-interface roles.

Fanless Aluminium Chassis with IP65 Front

An aluminium alloy enclosure provides silent, passive cooling rated for 7 x 24 hour operation. The front panel meets IP65 protection against dust and water jets, while the 10-point projected capacitive touchscreen withstands 200 million touches. Connectivity includes HDMI, VGA, 4 x USB2.0, LAN, audio in/out, 2 x COM and 12V DC input, plus a Mini PCIe slot with SIM holder for wireless expansion. Embedded buckle kits support panel mounting in a 522 x 315mm cut-out.

1920 x 1080 Resolution Decides Fit

The 21.5" TFT LED panel delivers a fixed 1920 x 1080 resolution at 250 cd/m² brightness with 1000:1 contrast and 80° viewing angles all round. Backlight life is rated at 30,000 hours minimum. This resolution determines whether the display matches your HMI software layout; buyers needing higher pixel density or a different aspect ratio should look elsewhere.

Høydepunkter

  • IP65 front protection seals out dust and water jets
  • 10-point projected capacitive touch enables precise multi-finger input
  • Fanless aluminium alloy cooling runs silently with no moving parts
  • 12 V DC input suits industrial power infrastructure
  • 1920 x 1080 resolution on 21.5 inch TFT LED panel

Spesifikasjoner

ModelA16-PA-215TPC-CE6A(I53)-8G256G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 3rd Gen
CPU Name1.70GHz
GPU/VGA TypeIntel HD Graphics
Memory Capacity8GB DDR3
SSD256GB
HDDNo
Screen Size21.5"
TouchscreenYes

Andre versjoner av denne modellen

5 flere i samme serie

Samme familie, annet minne, annen kjøler eller klokkefrekvens — sammenlign før du bestemmer deg.

Spørsmål om denne varen

What does the IP65 front-panel rating actually protect against in daily use?

The IP65 rating on the 21.5" TFT LED panel means the front is sealed against dust ingress and low-pressure water jets from any direction, so it survives wash-downs and dusty production lines without internal contamination.

What are the exact cut-out dimensions for the embedded mounting buckles supplied with the unit?

The embedded buckle kits require a rectangular opening of 522 x 315 mm; the overall chassis measures 527.8 x 321 x 54.5 mm and weighs 6 kg, so verify cabinet clearance before cutting.

How do I install an mSATA SSD or 2.5" SATA drive without removing the sealed front bezel?

Access the single mSATA slot and the 2.5" SATA bay through the rear service cover; secure the drive, reconnect the 12 V DC power, and the watchdog timer (255-level) will monitor boot health automatically.
