Black rectangular 17 inch portable monitor with resistive touchscreen and integrated stand

VIEWERA

VIEWERA V177TP 17" portable monitor 5-wire resistive touch D-Sub USB

SKU CH-V9N4-THAP8 MPN V177TP

17-inch portable touchscreen monitor with 5-wire resistive input, 1280 x 1024 resolution and D-Sub connectivity

  • Touchscreen Type5-wire Resistive
  • Cabinet ColorBlack
  • PanelTFT LCD
  • Screen Size17"
  • Resolution1280 x 1024
  • Viewing Angle170° (H) / 160° (V)
  • 5-wire resistive touchscreen responds to finger or stylus input
  • 170° horizontal and 160° vertical viewing angles maintain image clarity from the side
  • 1280 x 1024 resolution on a 17-inch panel provides sharp text and graphics
  • Single USB cable carries touch data while D-Sub handles analogue video
  • VESA 75 x 75 mm mounting points allow wall or arm installation

17" resistive-touch portable monitor

The VIEWERA V177TP is a 17 inch TFT LCD panel with a 1280 x 1024 resolution and a 5-wire resistive touchscreen. It accepts analog RGB video through a single D-Sub connector and draws touch data over USB. The display offers 250 cd/m2 brightness, a 500:1 contrast ratio and a 5ms response time.

Installation and common issues

The monitor includes a VGA cable, a USB cable and an external power adapter that operates from 100 to 240 VAC at 50 or 60 Hz. Touch functionality requires the driver supplied on the included CD to be installed on the host system. The resistive layer registers input from a finger, stylus or gloved hand but does not support multi-touch gestures.

Who this suits and who should look elsewhere

Industrial operators, kiosk builders and legacy-system integrators needing a compact 4:3 display with stylus or gloved-hand input will find this model fit for purpose. Buyers who want higher resolution, wider colour gamut, multi-touch capability or modern digital video inputs such as HDMI or DisplayPort should consider other options.

Høydepunkter

  • 5-wire resistive touchscreen responds to finger or stylus input
  • 170° horizontal and 160° vertical viewing angles maintain image clarity from the side
  • 1280 x 1024 resolution on a 17-inch panel provides sharp text and graphics
  • Single USB cable carries touch data while D-Sub handles analogue video
  • VESA 75 x 75 mm mounting points allow wall or arm installation

Spesifikasjoner

BrandViewEra
ModelV177TP
Touchscreen Type5-wire Resistive
Cabinet ColorBlack
PanelTFT LCD
Screen Size17"
Resolution1280 x 1024
Viewing Angle170° (H) / 160° (V)
Pixel Pitch0.264mm
Brightness250 cd/m2
Contrast Ratio500:1
Response Time5ms
Touchscreen InterfaceUSB
Input Video CompatibilityAnalog RGB
ConnectorsD-Sub
D-Sub1
DVINo
Power Supply100 - 240 VAC, 50/60Hz
Power Consumption19.7 watts (max.), 3 watts (standby)
Regulatory ApprovalsFCC-B, CE
VESA Compatibility - Mountable75 x 75mm
Dimensions14.88" (W) x 14.51" (H) x 7.09" (D) w/ stand
14.88" (W) x 12.50" (H) x 1.91" (D) w/o stand
Weight12.4lbs
Package ContentsV177TP, Power adapter, Power cord, VGA cable, USB cable, User manual, Touch Driver CD
Fraktvekt5.76 kg
Pakkestørrelse483 × 439 × 229 mm

Spørsmål om denne varen

How can I confirm the 5-wire resistive touchscreen is working correctly after connecting the USB cable?

Install the driver from the included CD, then verify the cursor follows a finger or stylus press across the 1280 x 1024 screen and the 170° horizontal viewing angle remains clear.

What cables and accessories come in the box so I can start using the monitor immediately?

The package includes the V177TP, power adapter, power cord, VGA cable, USB cable, user manual and touch driver CD.

Which video input does this model provide for connecting a source device?

The V177TP has a single D-Sub (VGA) connector for analog RGB input; no DVI or other video ports are present.
