Green circuit board with gold edge connector and black memory chips

OWC

OWC 8GB DDR3 1333 PC3-10600 CL9 2Rx4 240-pin 1.5V ECC Registered RDIMM for Dell Precision T5500

SKU CH-FM99-E0PD2

8GB DDR3 ECC registered RDIMM runs at 1333MHz for Dell Precision T5500 workstations

  • Capacity8GB
  • Type240-Pin DDR3 ECC RDIMM
  • SpeedDDR3 1333 (PC3 10600)
  • CAS LatencyCL9
  • Voltage1.5V
  • ECCYes

Capacity 8GB

  • ECC registered design protects data integrity in workstations and servers
  • 8 GB single module expands Dell Precision T5500 memory capacity
  • DDR3 1333 PC3-10600 CL9 matches system speed requirements
  • 240-pin 1.5 V registered DIMM fits T5500 motherboard slots
  • 2Rx4 organisation enables higher density in each channel

Dell Precision T5500 ECC RDIMM

This 8GB DDR3 module is built for the Dell Precision T5500 workstation. It delivers registered ECC memory for environments that require error correction and signal buffering. The single stick installs directly into a 240-pin DDR3 slot.

Registered ECC changes compatibility

Registered buffering and ECC make this module incompatible with standard desktop boards and with unbuffered memory. It is designed for workstation, server, NAS and router platforms that specifically support registered DIMMs. Mixing it with unbuffered sticks will prevent the system from posting.

DDR3 1333 CL9 1.5V 2Rx4

The module runs at 1333 MT/s with CAS latency 9 at 1.5 volts in a dual-rank 2Rx4 organisation. That speed, voltage and rank combination is the deciding factor for the Precision T5500 memory controller. Systems needing a different speed, voltage or rank layout cannot use this part.

Акценти

  • ECC registered design protects data integrity in workstations and servers
  • 8 GB single module expands Dell Precision T5500 memory capacity
  • DDR3 1333 PC3-10600 CL9 matches system speed requirements
  • 240-pin 1.5 V registered DIMM fits T5500 motherboard slots
  • 2Rx4 organisation enables higher density in each channel

Спецификации

BrandOWC
Part Number1R3D32R408GB
Capacity8GB
Type240-Pin DDR3 ECC RDIMM
SpeedDDR3 1333 (PC3 10600)
CAS LatencyCL9
Voltage1.5V
ECCYes
Buffered/RegisteredRegistered
Rank2Rx4
Heat SpreaderNo
Compatible SystemDell Precision T5500

Други версии на този модел

5 още от същата серия

Същото семейство, различна памет, охладител или честота — сравнете, преди да решите.

Въпроси за този артикул

Will the 240-pin DDR3 RDIMM need any firmware updates or battery replacements over its service life?

No firmware or battery maintenance is required; the module is a passive DDR3 component that operates at 1.5V and has no onboard firmware or power source.

What thermal limit appears first when the registered ECC module runs at 1333 MHz continuously in a Dell Precision T5500?

The DDR3 chips are rated for 1.5 V operation; sustained full-load use will hit the JEDEC maximum case temperature before any electrical limit is reached.

How much power does the 8 GB 2Rx4 registered DIMM draw and how much heat does it add when the workstation runs all day?

At 1.5 V the module draws only a few watts, adding minimal heat; the registered buffer and ECC logic increase draw slightly over unbuffered DDR3 but remain well within the T5500 cooling capacity.
