Corn Electronics
Corn Electronics ZH-120 ARGB 3-in-1 case fan 120mm 500-1500 RPM black
Three 120 mm ARGB fans with hydraulic bearings, 500-1500 RPM, 20.1-60.45 CFM airflow and 23.8-29.3 dB(A) noise, plus wire-free daisy-chaining for simple 5 V motherboard sync
- Fan Counts3 Fans
- Fan ControllerNo Controller
- TypeCase Fan
- Fan Thickness25mm
- Bearing TypeHydro Bearing
- RPM500-1500±10%RPM
- Quiet operation at 23.8 dB(A) minimum noise level
- Strong airflow up to 60.45 CFM for effective cooling
- Addressable RGB lighting via 5 V 3-pin motherboard sync
- Wire-free daisy-chain design simplifies three-fan installation
- Hydraulic bearing rated for 40000 hours at 25 °C
Three-Fan ARGB Kit
This pack contains three 120 mm case fans with addressable RGB lighting and a black frame. Each unit uses a hydraulic bearing rated for 40000 hours at 25 °C. The fans connect via a 4-pin PWM header for speed control and a separate 3-pin 5 V ARGB header for motherboard synchronisation. The wire-free splicing design lets the three fans link together without extra cables.
500-1500 RPM Range
At the low end the fans spin at 500 RPM, delivering 20.1 CFM and 0.42 mmH2O at 23.8 dB(A). At maximum they reach 1500 RPM, moving 60.45 CFM and 1.29 mmH2O while producing 29.3 dB(A). The 25 mm thickness fits standard mounting points. This range suits typical chassis airflow but may lack static pressure for dense radiators or restrictive filters.
Upgrade from Single Stock Fans
The kit replaces a lone rear exhaust or a pair of basic fixed-speed fans, adding balanced intake and exhaust plus coordinated lighting. Builders who need more than three mounting points or who require higher static pressure for liquid-cooling radiators should look at additional or specialised models. The hydraulic bearing offers longer life than sleeve alternatives in the same price tier.
Fordele
- Quiet operation at 23.8 dB(A) minimum noise level
- Strong airflow up to 60.45 CFM for effective cooling
- Addressable RGB lighting via 5 V 3-pin motherboard sync
- Wire-free daisy-chain design simplifies three-fan installation
- Hydraulic bearing rated for 40000 hours at 25 °C
Specifikationer
| Brand | JONSBO |
|---|---|
| Series | ZH-120 ARGB |
| Fan Counts | 3 Fans |
| Fan Controller | No Controller |
| Type | Case Fan |
| Fan Thickness | 25mm |
| Bearing Type | Hydro Bearing |
| RPM | 500-1500±10%RPM |
| Air Flow | 20.1-60.45CFM |
| Noise Level | 23.8-29.3dB(A) |
| Power Connector | 4 Pin |
| Color | Black |
| LED | ARGB |
| Dimensions | 120 × 120 × 25 mm |
Spørgsmål om denne vare
Will the 120 mm ZH-120 fans fit the same mounting holes as my current 120 mm fans?
Yes, the 120 × 120 × 25 mm dimensions match the standard 120 mm mounting pattern used by most cases and radiators.
How can I confirm the ARGB lighting is synchronised with my motherboard after connecting the 5 V 3-pin headers?
The LEDs should respond to your motherboard’s ARGB software immediately; if colours and effects change in sync with the rest of the system, the 5 V 3-pin connection is working correctly.
Does the pack include a fan controller or do I need to buy one separately for the three fans?
The box contains three fans with 4-pin PWM and 5 V 3-pin ARGB cables; no controller is included, so you will need enough motherboard headers or a separate hub to run all three.
