Intel
Intel E10G42BTDABLK Dual-Port 10G Ethernet Adapter
Dual-port 10Gbps Ethernet adapter fits a PCIe 2.0 x8 low-profile slot and delivers throughput above 1Gbps
- WAN Ports2 x 10Gbps WAN
- InterfacePCI Express 2.0 x8 (Low Profile)
- StandardsIEEE 802.3, 802.3u
- LAN Ports2 x 10G
- Throughput> 1Gbps
- Dimensions6.6 in × 2.7 in × 0.7 in
- Dual 10 Gbps ports deliver high-throughput networking
- PCI Express 2.0 x8 interface provides ample bandwidth headroom
- Low-profile form factor fits compact server chassis
- IEEE 802.3 and 802.3u compliance ensures broad interoperability
- Lightweight 0.5 lb design adds minimal load to the system
Dual-Port 10G Ethernet Adapter
The Intel E10G42BTDABLK adds two 10 Gbps Ethernet ports to a server or workstation through a PCI Express 2.0 x8 slot. It is built for administrators who need high-throughput wired connectivity for storage, virtualisation or backbone links.
PCI Express 2.0 x8 low-profile interface
The card requires a free PCIe 2.0 x8 slot and ships with a low-profile bracket for compact chassis. Systems limited to x4 electrical width or lacking a low-profile opening cannot install this adapter.
Thermals and power in normal use
The compact 6.6 by 2.7 by 0.7 inch form factor relies on system airflow for cooling. With no active fan on the board, acoustic output is negligible and power draw stays within the PCIe slot envelope during typical 10 Gbps traffic.
Fordele
- Dual 10 Gbps ports deliver high-throughput networking
- PCI Express 2.0 x8 interface provides ample bandwidth headroom
- Low-profile form factor fits compact server chassis
- IEEE 802.3 and 802.3u compliance ensures broad interoperability
- Lightweight 0.5 lb design adds minimal load to the system
Specifikationer
| WAN Ports | 2 x 10Gbps WAN |
|---|---|
| Interface | PCI Express 2.0 x8 (Low Profile) |
| Standards | IEEE 802.3, 802.3u |
| LAN Ports | 2 x 10G |
| Throughput | > 1Gbps |
| Dimensions | 6.6 in × 2.7 in × 0.7 in |
| Weight | 0.5 LB |
| Brand | Dell |
| Model | X520-DA2 |
| Part Number | X520-DA2 |
| Package Contents | Intel X520-DA2 Dual-Port 10Gb Ethernet Network Adapter Low-profile bracket |
Spørgsmål om denne vare
What does the 10 Gbps WAN rating mean when the adapter is installed in a server?
Each port can move data at up to 10 Gbps, giving the server two independent 10 Gbps links to the network.
What does the PCI Express 2.0 x8 interface limit in practice?
The x8 lane width caps the adapter at the PCIe 2.0 x8 maximum throughput, which is shared between the two 10 Gbps ports.
What does the low-profile PCIe 2.0 x8 form factor require for installation?
It fits a standard low-profile PCIe x8 or longer slot and includes a low-profile bracket for slim chassis.
