Small rectangular camera board with CS lens and two flat cables attached

MCDODO

MCDODO IMX477 Pi HQ Camera 12.3MP 6mm CS Lens 300mm Cable

SKU CH-V3CW-ZBX8E

A 12.3 MP camera with 6 mm CS lens and two 300 mm cables for Raspberry Pi 5, 4B, 3B+, Zero and Zero 2W

  • TypeSingle Board Computers
  • 3 MP resolution captures sharp 4056 x 3040 stills
  • 6 mm CS lens provides manual focus and adjustable aperture
  • 300 mm cables fit Pi 5, 4B, 3B+, Zero and Zero 2W
  • 22-pin and 15-22 pin cables included for direct board connection
  • IMX477 sensor delivers clear images for maker and IoT projects

Product Identity

The MCDODO IMX477 Pi HQ Camera is a 12.3MP development board accessory designed for Raspberry Pi projects. It includes a 6mm focal length CS lens with manual focus and adjustable aperture. Two 300mm cables (22-22pin and 15-22pin) provide connectivity across multiple board revisions.

Suitability

Makers needing a high-resolution camera module with integrated lens for Raspberry Pi 5, 4B, 3B+, 3B, 2, Zero, and Zero 2W will find this kit convenient. Builders requiring automatic autofocus, motorised zoom, or native support for Nvidia Jetson platforms should consider alternative modules.

Deciding Specification

The Sony IMX477 sensor delivers a maximum still resolution of 4056 x 3040 pixels. This 12.3MP output defines the image detail available for computer vision, photography, or streaming applications on compatible single-board computers.

Fordele

  • 3 MP resolution captures sharp 4056 x 3040 stills
  • 6 mm CS lens provides manual focus and adjustable aperture
  • 300 mm cables fit Pi 5, 4B, 3B+, Zero and Zero 2W
  • 22-pin and 15-22 pin cables included for direct board connection
  • IMX477 sensor delivers clear images for maker and IoT projects

Specifikationer

TypeSingle Board Computers

Spørgsmål om denne vare

How much power does the IMX477 camera draw when recording continuously on a Raspberry Pi 5?

The IMX477 camera is powered directly from the Raspberry Pi board through the 22-pin MIPI CSI interface, so its draw is included in the Pi's overall consumption and does not require a separate power supply.

Which Raspberry Pi boards and cables are needed to use this IMX477 camera kit?

The kit includes a 300 mm 22-22 pin cable for Raspberry Pi 5 and Zero, plus a 300 mm 15-22 pin cable for Raspberry Pi 4B and 3B+, so you only need a compatible Pi board and the supplied cable.

Will the 6 mm CS lens work on an older Raspberry Pi 3B+ with the 15-22 pin cable?

Yes, the 6 mm CS lens is pre-attached to the IMX477 module and the 15-22 pin cable connects the camera to the Raspberry Pi 3B+ CSI port for full functionality.
