Gray fanless aluminum mini PC, book-style vertical form, Phoenix power terminal, four LAN ports, HDMI and DP outputs

partaker

partaker I24 Core i3 12300T 32G 512G barebone mini PC

SKU CH-943A-Y2E0N

Fanless industrial mini PC with a Core i3 12300T, 32 GB DDR5, 512 GB SATA SSD, four Gigabit LAN ports, dual 4K video outputs, and two optically isolated RS485 ports for reliable 24/7 edge deployment

  • ColorGray
  • CPU TypeIntel Core i3 12th Gen

I24 CPU I3 12300T 32GB RAM / 512GB SSD

  • Fanless aluminium chassis operates silently from -20°C to 50°C
  • Quad Gigabit LAN ports (3 x I210-AT + 1 x I219-LM) for redundant networking
  • Core i3-12300T 4C/8T up to 4.2 GHz with dual DDR5 4800 SODIMM slots
  • Dual 4K 3840x2160 @60Hz outputs via HDMI and DP
  • Flexible DC 12-24V Phoenix terminal input with watchdog 0-255 and TPM 2.0

Industrial Fanless Mini PC

The Partaker I24 is a book-style barebone built around an Intel Core i3-12300T desktop processor with four cores and eight threads reaching 4.2 GHz. Its all-aluminum chassis passively dissipates 35-69 W TDP without moving parts, making it suitable for continuous 24/7 operation in harsh environments from -20 °C to 50 °C. It arrives with 32 GB of DDR5-4800 memory and a 512 GB M.2 2280 SATA SSD installed, ready for immediate deployment in automation, medical or logistics roles.

Suited For Control Cabinets Not Consumer Desks

This unit targets integrators who need quad Gigabit Ethernet ports, two optically isolated RS-485 serial links and dual 4K60 video outputs over HDMI and DP for HMI or surveillance panels. The 12-24 V DC Phoenix terminal, watchdog timer, TPM 2.0 and flexible DIN-rail or wall mounting address industrial power and reliability requirements. Buyers seeking consumer features such as integrated Wi-Fi, Bluetooth, audio jacks or a compact silent living-room media player should look at something else.

Storage Interface Is SATA Only

The single M.2 2280 slot and the mSATA socket both support SATA protocol SSDs, so the pre-installed 512 GB drive and any future upgrades must be SATA devices. An additional full-size Mini PCIe slot with a Nano SIM holder allows 4G or Wi-Fi expansion cards for remote connectivity. Verify that your storage budget and performance expectations align with SATA throughput before specifying this platform.

Fordele

  • Fanless aluminium chassis operates silently from -20°C to 50°C
  • Quad Gigabit LAN ports (3 x I210-AT + 1 x I219-LM) for redundant networking
  • Core i3-12300T 4C/8T up to 4.2 GHz with dual DDR5 4800 SODIMM slots
  • Dual 4K 3840x2160 @60Hz outputs via HDMI and DP
  • Flexible DC 12-24V Phoenix terminal input with watchdog 0-255 and TPM 2.0

Specifikationer

ColorGray
CPU TypeIntel Core i3 12th Gen

Andre versioner af denne model

5 flere i samme serie

Samme familie, men med anden hukommelse, køler eller clockfrekvens — sammenlign, før du bestemmer dig.

Spørgsmål om denne vare

Should I pick the 32 GB RAM and 512 GB SSD configuration or add more memory later?

The unit ships with 32 GB DDR5 4800 MT/s installed across two SODIMM slots; the board supports up to 64 GB, so you can add another matched pair if workloads demand it.

What does the Core i3 12300T 4.2 GHz turbo mean for sustained industrial workloads?

The 4-core 8-thread CPU boosts to 4.20 GHz within a 35-69 W TDP envelope; the fanless aluminium chassis dissipates that heat passively across the full -20 °C to 50 °C operating range.

Are the four LAN ports all full Gigabit and what limits real throughput?

Three Intel I210-AT and one I219-LM controllers each provide 1 Gbps links; actual throughput is capped by the Gigabit Ethernet standard and the PCIe lanes feeding the chipset.
