SonicWall
SonicWall TZ270 HA firewall appliance 02-SSC-6447
High-availability desktop firewall with eight Gigabit Ethernet ports, two USB 3.0 ports, and 2 Gbps inspection throughput for small-branch redundancy
- TypeWired
- Form FactorDesktop
- StandardsTCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHC
- ProtocolsBGP, OSPF, RIPv1/v2, static routes, policy-based routing
- SecurityDeep Packet Inspection services: Gateway Anti-Virus, Anti-Sp
- Encryption StandardDES, 3DES, AES
De overstregede versioner findes, men er ikke på lager her.
Option High Availability
- High-availability secondary unit for resilient failover
- 8×1 GbE ports plus 2 USB 3.0 and console for flexible connectivity
- Deep packet inspection with gateway AV, anti-spyware, IPS and DPI SSL
- Firewall throughput 2 Gbps; threat prevention 750 Mbps
- Certified FIPS 140-2 Level 2, ICSA firewall and IPv6/USGv6 ready
HA Secondary Unit
The SonicWall TZ270 HA appliance serves as a dedicated backup firewall in a high-availability pair. It is built for small offices and lean branches that require continuous uptime without managing a second active device. The desktop form factor fits standard workspaces while delivering enterprise-grade security services.
Interface Constraints
Connectivity is limited to eight Gigabit Ethernet ports, two USB 3.0 ports and a single console connection. Wireless operation is restricted to the 2.4 GHz and 5 GHz bands. Throughput ceilings are fixed at 2 Gbps for firewall inspection, 750 Mbps for threat prevention and 1 Gbps for application inspection, IPS and anti-malware scanning.
HA Pairing Requirement
This unit functions only as the secondary member of an HA pair; it cannot operate as a standalone primary firewall. Buyers who need a single self-sufficient appliance or an active-active cluster must select a different model. The part number 02-SSC-6447 identifies this specific HA role.
Fordele
- High-availability secondary unit for resilient failover
- 8×1 GbE ports plus 2 USB 3.0 and console for flexible connectivity
- Deep packet inspection with gateway AV, anti-spyware, IPS and DPI SSL
- Firewall throughput 2 Gbps; threat prevention 750 Mbps
- Certified FIPS 140-2 Level 2, ICSA firewall and IPv6/USGv6 ready
Specifikationer
| Brand | SONICWALL |
|---|---|
| Series | TZ270 Series |
| Model | TZ270 HA |
| Part Number | 02-SSC-6447 |
| Type | Wired |
| Form Factor | Desktop |
| Standards | TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
| Protocols | BGP, OSPF, RIPv1/v2, static routes, policy-based routing |
| Security | Deep Packet Inspection services: Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL Content Filtering Service (CFS): HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists Comprehensive Anti-Spam Service Application Visualization Application Control Capture Advanced Threat Protection |
| Encryption Standard | DES, 3DES, AES |
| Frequency Band | 2.4 GHz/5 GHz |
| Ports | 8x1GbE, 2 USB 3.0, 1 Console |
| Simultaneous Sessions | 750000 |
| Maximum Users | 1000+ |
| VPN | Firewall / VPN Performance Firewall inspection throughput: 2 Gbps Threat prevention throughput: 750 Mbps Application inspection throughput: 1 Gbps IPS throughput: 1 Gbps Anti-malware inspection throughput: 750 Mbps TLS/SSL inspection and decryption throughput (DPI SSL): 300 Mbps IPSec VPN throughput: 750 Mbps Connections per second: 6,000 Maximum connections (SPI): 750,000 Maximum connections (DPI): 150,000 Maximum connections (DPI SSL): 25,000 VPN Site-to-site VPN tunnels 50 IPSec VPN clients (maximum) 5 (200) SSL VPN licenses (maximum) 1 (50) Encryption/authentication: DES, 3DES, A |
| Throughput | 1 Gbps |
| OS Support | Windows, Mac, Linux |
| Certifications | FIPS 140-2 Level 2 (with Suite B), IPv6/USGv6, ICSA Network Firewall, ICSA Firewall Enterprise, ISCA Network Antivirus / AntiMalware |
| Compliance | FCC Class B, ICES Class B, CE (EMC, LVD, RoHS), C-Tick, VCCI Class B, UL, cUL, CB, Mexico CoC by UL, WEEE, REACH, BSMI, KCC/ MSIP, ANATEL |
| Power Input | 36W external |
| Max Power Consumption | 16.84W |
| Features | High availability: Active/Standby with stateful synchronization |
| Dimensions | 3.5x13.5x19 (cm) 1.8x5.3x7.5 (in) |
| Weight | 0.82 kg / 1.81 lbs |
| Forsendelsesvægt | 1.32 kg |
| Pakkestørrelse | 229 × 229 × 76 mm |
Andre versioner af denne model
5 flere i samme serie
Samme familie, men med anden hukommelse, køler eller clockfrekvens — sammenlign, før du bestemmer dig.
SonicWall
SonicWall TZ270 Total Secure (1Y APSS) 02-SSC-6843 firewall appliance
- Wired
- Desktop
594,99 US$
0.00762514BTC
På lager
Spørgsmål om denne vare
Which TZ270 model should I choose for a High Availability secondary unit?
The 02-SSC-6447 is the TZ270 HA appliance, built specifically as the backup unit in an active-passive HA pair.
What does the 750 Mbps threat prevention throughput mean for daily traffic?
It is the maximum sustained rate at which the appliance can inspect traffic with gateway anti-virus, anti-spyware and intrusion prevention all enabled.
How do the 8×1GbE ports and 36 W power input limit deployment?
Eight Gigabit Ethernet interfaces provide LAN, WAN and DMZ connectivity, while the 36 W external adapter means no redundant power supply is included on this model.
