Ten pairs of black male and female solar cable connectors with cylindrical bodies and locking tabs

The Perfect Part

The Perfect Part Solar Cable Connectors 10 Pairs Male Female Black

SKU CH-PM9R-BHWBZ

Ten pairs of male and female solar cable connectors rated to 30 A with IP67 mated protection from -40 °C to +90 °C

  • TypeDC Power Supplies
  • Engine BrandThe Perfect Part
  • Starter TypeRecoil
  • MaterialPPO + ABS
  • Temperature Range-40 C ~ +90 C
  • Primary Openings1

Pack 10 Pairs

  • 10 pairs included for quick solar array assembly
  • Silver-plated copper contacts deliver 30 A on 6 mm² cable
  • IP67 mated rating seals out dust and water
  • UL94-V0 flame class resists fire up to 90 °C
  • Wide -40 °C to +90 °C range suits extreme climates

Solar cable connectors, 10 pairs

These black male and female connectors are built for photovoltaic wiring. The PPO and ABS bodies with PC/PA insulation resist UV, rain and snow. They operate from -40 °C to +90 °C and meet UL94-V0 or UL94-5VA flame ratings.

Rated current and cable fit

Rated current is 22 A with 2.5 mm² cable and 30 A with 4 mm² or 6 mm² cable. Suitable cables are 2.5 mm², 4 mm² and 6 mm² (AWG 14, 12, 10). Pin diameter is 4.0 mm, contact resistance 0.2 mΩ, insertion and withdrawal force 50 N each.

Outdoor installers needing IP67 mated seals

Installers who need IP67 protection when mated and IP2X when unmated will find these suitable. Buyers who require connectors for larger cable cross-sections or higher current ratings should look elsewhere.

Fordele

  • 10 pairs included for quick solar array assembly
  • Silver-plated copper contacts deliver 30 A on 6 mm² cable
  • IP67 mated rating seals out dust and water
  • UL94-V0 flame class resists fire up to 90 °C
  • Wide -40 °C to +90 °C range suits extreme climates

Specifikationer

TypeDC Power Supplies
Engine BrandThe Perfect Part
Starter TypeRecoil
MaterialPPO + ABS
Temperature Range-40 C ~ +90 C
Primary Openings1
Secondary Openings1
Wire TypeAI
Features10-pack; Color: Black; Material: PPO + ABS; Insulation Material: PC/PA, black

Andre versioner af denne model

4 flere i samme serie

Samme familie, men med anden hukommelse, køler eller clockfrekvens — sammenlign, før du bestemmer dig.

Spørgsmål om denne vare

How much current can the 30 A rating actually carry on a 6 mm² cable in a working array?

The connector is rated for 30 A when used with 4 mm² or 6 mm² cable, so a properly crimped 6 mm² run will carry the full 30 A continuously.

What does the IP67 rating mean once the pair is mated on the roof?

When the male and female halves are fully mated the joint meets IP67, giving dust-tight protection and survival in 1 m of water for 30 minutes.

Will these fit standard 4 mm diameter pins and what cable sizes do they accept?

Yes, the pin diameter is 4.0 mm and the connectors accept 2.5 mm², 4 mm² and 6 mm² cables (AWG 14, 12, 10).
