Dell Quadro P2200 workstation card, single-slot, four DisplayPorts, matte black finish

DELL

DELL 5.1 Quadro P2200 5GB GDDR5X workstation graphics card

SKU CH-NJ1Z-WZ7KS MPN 5.1

A workstation graphics card with 5 GB GDDR5X memory, 1280 CUDA cores and four DisplayPort 1.4 outputs driving up to four 5K displays at 60 Hz from a 75 W single-slot design

  • Memory TypeGDDR5X
  • 5 GB GDDR5X memory handles large models and textures
  • 1280 CUDA cores accelerate rendering and compute workloads
  • Four DisplayPort 1.4 outputs drive up to four 5K displays at 60 Hz
  • 75 W maximum power draw fits single-slot workstation chassis
  • PCI Express 3.0 x16 interface provides 160-bit memory bandwidth up to 200 GB/s

Dell Quadro P2200 5GB workstation GPU

This Dell Quadro P2200 workstation graphics card delivers 5GB of GDDR5X memory across a 160-bit interface with up to 200 GB/s bandwidth. It is built for professionals who need certified stability in CAD, DCC and visualization workflows. The PCI Express 3.0 x16 interface fits standard workstation slots. Buyers who require more than 5GB of frame buffer or dual-slot cooling capacity should consider other options.

Active single-slot cooler at 75W

The card uses an active thermal solution within a 4.4 H x 7.9 L single-slot form factor while drawing a maximum of 75 W. Four DisplayPort 1.4 connectors drive up to four simultaneous displays at resolutions such as 4096x2160 at 120Hz or 5120x2880 at 60Hz. Shader Model 5.1, OpenGL 4.6, DirectX 12.0 and Vulkan 1.1 provide broad API coverage for professional applications. Systems limited to a single-slot bracket or a lower power budget will find this design compatible.

1280 CUDA cores for sustained compute

Under continuous load the 1280 CUDA cores maintain performance for CUDA, DirectCompute and OpenCL workloads without relying on short burst behaviour. The 75 W power ceiling and active cooler are sized for steady-state operation in rack or tower workstations. Display output remains stable across four DP 1.4 Multi-Stream ports during extended rendering or simulation sessions. Users needing higher sustained throughput or multi-GPU scaling should evaluate larger configurations.

Kohokohdat

  • 5 GB GDDR5X memory handles large models and textures
  • 1280 CUDA cores accelerate rendering and compute workloads
  • Four DisplayPort 1.4 outputs drive up to four 5K displays at 60 Hz
  • 75 W maximum power draw fits single-slot workstation chassis
  • PCI Express 3.0 x16 interface provides 160-bit memory bandwidth up to 200 GB/s

Tekniset tiedot

Memory TypeGDDR5X

Kysymyksiä tästä tuotteesta

How do I install the Dell Quadro P2200 into a PCI Express 3.0 x16 slot without bending the single-slot bracket?

Align the gold-edge connector squarely with the motherboard PCI Express 3.0 x16 slot, press evenly along the top edge until the retention clip clicks, then secure the 4.4 H × 7.9 L single-slot bracket with one screw; the step most often missed is fully seating the connector before tightening the bracket.

What maintenance will the active thermal solution on this 75 W card need over time?

The active cooler draws heat off the 1280 CUDA core GPU; plan to blow dust from the heatsink fins and fan blades every 6–12 months with compressed air, and listen for bearing noise that signals a fan replacement.

Which limit appears first when driving four 4096×2160 displays at 120 Hz continuously?

The 160-bit memory interface caps bandwidth at 200 GB/s, so sustained 4× 4K 120 Hz workloads hit the memory throughput ceiling before the 75 W power limit or GPU compute saturates.
