Green ATX server motherboard with silver CPU socket, eight black DIMM slots, five PCIe x16 slots, dual M.2 sockets

TYAN

TYAN S8030GM2NE server motherboard AMD EPYC 7002/7003 SP3 DDR4 ATX

SKU CH-98ZP-J9ZJ9 MPN S8030GM2NE

ATX server board with AMD EPYC SP3 socket, eight DDR4 channels, twelve SATA ports and dual Gigabit LAN

  • CPU Socket TypeAMD Socket SP3
  • CPU TypeAMD EPYC 7002 Series / AMD EPYC 7003 Series
  • Supports AMD EPYC 7002 and 7003 series processors with SP3 socket
  • Eight DDR4 channels and eight DIMM slots enable up to 2,048 GB LRDIMM capacity
  • Five PCI-Express Gen4 x16 slots provide high-bandwidth expansion for accelerators and networking
  • Dual Intel I210 GbE plus dedicated IPMI LAN deliver redundant management and data paths
  • Two M.2 slots and fifteen SATA ports via Mini SAS HD and onboard connectors offer flexible storage options

Socket SP3 EPYC server board

The TYAN S8030GM2NE is an ATX motherboard built for AMD EPYC 7002 and 7003 series processors in the SP3 socket. It targets system integrators and IT teams assembling single-socket servers or workstations that need high core counts and large memory capacity in a standard form factor.

Eight-channel DDR4 up to 2 TB LRDIMM

The board provides eight DIMM slots wired for eight memory channels per CPU, supporting ECC RDIMM up to 512 GB and LRDIMM up to 1 024 GB or 2 048 GB. This capacity ceiling is the specification that determines whether the platform fits memory-intensive workloads such as virtualization hosts or in-memory databases.

ATX layout with dual 8-pin CPU power

Installation follows a conventional ATX footprint of 305.0 x 250.8 mm with a 24-pin main connector and two 8-pin CPU power plugs. Builders should verify chassis clearance for the five full-length PCIe Gen4 x16 slots and confirm that the power supply delivers both 8-pin EPS cables, as a single 8-pin will not meet the 240 W CPU rating.

Kohokohdat

  • Supports AMD EPYC 7002 and 7003 series processors with SP3 socket
  • Eight DDR4 channels and eight DIMM slots enable up to 2,048 GB LRDIMM capacity
  • Five PCI-Express Gen4 x16 slots provide high-bandwidth expansion for accelerators and networking
  • Dual Intel I210 GbE plus dedicated IPMI LAN deliver redundant management and data paths
  • Two M.2 slots and fifteen SATA ports via Mini SAS HD and onboard connectors offer flexible storage options

Tekniset tiedot

BrandTYAN
ModelS8030GM2NE
CPU Socket TypeAMD Socket SP3
CPU TypeAMD EPYC 7002 Series / AMD EPYC 7003 Series
Lähetyspaino1.88 kg
Pakkauksen mitat385 × 339 × 84 mm

Kysymyksiä tästä tuotteesta

What does the 240 W CPU support mean for my build?

The board can power processors rated up to 240 W, so you can install high-wattage EPYC 7002 or 7003 CPUs without exceeding the VRM design limit.

What speed does the PCIe Gen4 x16 interface actually deliver?

Each of the five slots is wired for PCIe Gen4 x16, so the electrical ceiling is the Gen4 x16 rate; the CPU's lane budget decides how many slots can run at that width simultaneously.

What physical space and power connectors does this ATX board need?

It measures 12.0 x 9.9 inch, fits standard ATX cases, and requires one 24-pin plus two 8-pin power connectors.
