Green PCB network card with four RJ-45 ports and full-height metal bracket

DELL

DELL TMGR6 (KH08P) BCM5719 Gigabit Quad Port PCIe 2.0 x4 Network Card

SKU CH-PKYY-6CRX8

Adds four gigabit RJ-45 ports over a PCIe 2.0 x4 slot with full and half-height brackets included

  • StandardsIEEE 802.3, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3x, IEEE 802.
  • Speed10/100/1000 Mbps
  • ConnectorsRJ-45 x 4
  • Interfacex4. Operable with PCI-E x4; x8 and x16
  • LEDsFour LED indicators(10,100,1000 activity)
  • Wake On LANYes
  • Four Gigabit ports on a single PCIe 2.0 x4 slot
  • Auto-negotiation at 10/100/1000 Mbps for flexible cabling
  • Full and half-height brackets fit any server chassis
  • Broadcom BCM5719 controller with IEEE 802.3, 802.3z, 802.1Q, 802.3x, 802.3az compliance
  • Plug-and-play support for Red Hat Linux, Windows Server, Citrix XenServer 6.0, VMware vSphere 5.0 and 4.1

Quad-port Gigabit server adapter

The DELL TMGR6 (KH08P) is a PCIe 2.0 x4 network card built around the Broadcom BCM5719 controller. It delivers four RJ-45 ports that auto-negotiate at 10, 100 or 1000 Mbps. The card targets servers and workstations that need multiple copper links in a single slot.

Full-height and low-profile brackets included

The board measures 13.2 cm by 6.86 cm and fits a PCIe x4, x8 or x16 slot. Both full-height and half-height brackets are supplied so the adapter works in standard rackmount chassis or slim enclosures. Wake-on-LAN is supported and four LEDs show link speed and activity per port.

Suits admins adding copper density to a server

The card is a good match for administrators expanding a Linux, Windows Server, XenServer or vSphere host with extra Gigabit links. It will not serve builds that require 10 GbE, fibre connectors or a single-port form factor.

Ciri-ciri utama

  • Four Gigabit ports on a single PCIe 2.0 x4 slot
  • Auto-negotiation at 10/100/1000 Mbps for flexible cabling
  • Full and half-height brackets fit any server chassis
  • Broadcom BCM5719 controller with IEEE 802.3, 802.3z, 802.1Q, 802.3x, 802.3az compliance
  • Plug-and-play support for Red Hat Linux, Windows Server, Citrix XenServer 6.0, VMware vSphere 5.0 and 4.1

Spesifikasi

BrandDELL / Broadcom
ModelTMGR6 (KH08P) / BCM5719
StandardsIEEE 802.3, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3az
Speed10/100/1000 Mbps
ConnectorsRJ-45 x 4
Interfacex4. Operable with PCI-E x4; x8 and x16
LEDsFour LED indicators(10,100,1000 activity)
Wake On LANYes
DimensionsLenght: 13.2 cm x Width: 6.86 cm
Weight3 oz
Package ContentsTmgr6 Full and Half Profile NIC

Soalan tentang produk ini

How many RJ-45 ports does the TMGR6 expose for 1 Gbps links?

The card provides four RJ-45 ports, each supporting 10, 100 or 1000 Mbps auto-negotiation.

What is the typical power draw of the BCM5719 when all four ports run at 1 Gbps continuously?

The Broadcom BCM5719 controller is designed for low-power operation and supports IEEE 802.3az Energy Efficient Ethernet to reduce consumption during sustained traffic.

Which PCI Express slot widths can the TMGR6 operate in?

The x4 interface works in PCIe 2.0 x4, x8 or x16 slots, and the package includes both full-height and half-height brackets for different chassis.
