Green rectangular Micro ATX motherboard with silver CPU socket, two black DDR4 slots, silver heatsinks and rear I/O panel

GIGABYTE

GIGABYTE B760M K DDR4 LGA 1700 Intel B760 64GB Micro ATX motherboard

SKU CH-WEQ6-YTKZH

Micro ATX Intel B760 board with LGA 1700 socket for 12th, 13th and 14th Gen CPUs, two DDR4 DIMM slots up to 64GB, one PCIe 4.0 x16 slot, one PCIe 3.0 x1 slot, one M.2 and four SATA ports.

  • CPU Socket TypeLGA 1700
  • CPU TypeLGA1700 slot for 14th, 13th and 12th Gen Intel ® Core ™, Pen
  • ChipsetIntel B760
  • Maximum Memory Supported64GB
  • PCI SlotsBased on CPU: 1 PCI-E x16 slot, supporting PCIe 4.0 and x16
  • SATA RAID1XM.2 interface, 4xSATA III interface
  • Supports 14th, 13th and 12th Gen Intel Core processors with LGA 1700 socket
  • Up to 64GB DDR4 memory across two DIMM slots for high capacity
  • PCIe 4.0 x16 slot plus PCIe 3.0 x1 slot for graphics and expansion
  • Realtek GbE LAN and 7.1 channel HD audio for networking and sound
  • Micro ATX 23x21.5cm form factor fits compact builds with SATA connectivity

B760M K DDR4 LGA 1700 Micro ATX

This Intel B760 motherboard fits a micro ATX form factor and accepts 12th, 13th and 14th Gen Core, Pentium Gold and Celeron processors in an LGA 1700 socket. Two DDR4 DIMM slots support up to 64GB of system memory for everyday productivity and gaming builds.

PCIe 4.0 x16 and 3.0 x1 sustained throughput

The primary expansion slot runs at PCIe 4.0 x16 directly from the CPU, while the chipset provides a PCIe 3.0 x1 slot for add-in cards. Four SATA III ports and one M.2 interface handle storage traffic without sharing bandwidth with the graphics slot during prolonged workloads.

Realtek audio and GbE with 6 USB 3.2 Gen 1 ports

Integrated Realtek audio supports 7.1 channel output and S/PDIF, while a Realtek GbE controller delivers wired networking at 1 Gbps, 100 Mbps and 10 Mbps. Four rear and two header USB 3.2 Gen 1 ports plus two rear USB 2.0 ports provide peripheral connectivity under normal operating temperatures.

Poudarki

  • Supports 14th, 13th and 12th Gen Intel Core processors with LGA 1700 socket
  • Up to 64GB DDR4 memory across two DIMM slots for high capacity
  • PCIe 4.0 x16 slot plus PCIe 3.0 x1 slot for graphics and expansion
  • Realtek GbE LAN and 7.1 channel HD audio for networking and sound
  • Micro ATX 23x21.5cm form factor fits compact builds with SATA connectivity

Specifikacije

BrandGIGABYTE
SeriesGIGABYTE B760M K DDR4
ModelGIGABYTE B760M K DDR4
CPU Socket TypeLGA 1700
CPU TypeLGA1700 slot for 14th, 13th and 12th Gen Intel ® Core ™, Pentium ® Gold and Celeron ® processors
2. L3 cache depends on CPU
ChipsetIntel B760
Maximum Memory Supported64GB
PCI SlotsBased on CPU:
1 PCI-E x16 slot, supporting PCIe 4.0 and x16 operating specifications
Based on chipset:
1 PCI-E x1 slot, supporting PCIe 3.0 and x1 operating specifications
SATA RAID1XM.2 interface, 4xSATA III interface
Audio Chipset1. Integrated Realtek ® audio chip
2. Support High Definition Audio
3. Support 2/4/5 1/7.1 channels
4. Support S/PDIF output
LAN ChipsetIntegrated Realtek ® GbE network chips (1 Gbps/100 Mbps/10 Mbps)
Onboard USBBased on chipset:
1.6 USB 3.2 Gen 1 ports (4 in the rear window IO, 2 need to be connected from the USB socket in the main board via the cable)
2.6 USB 2.0/1 (2 in the rear window IO, 4 need to be connected from the main board USB socket via cable)

Vprašanja o tem izdelku

How hot or noisy does the B760M K DDR4 run during all-day use?

The board itself has no active cooling; thermal and acoustic output depends on the CPU cooler and case airflow you provide.

What components must I already own for this motherboard to function?

You need an LGA 1700 processor, DDR4 memory modules, a Micro ATX compatible case, a power supply with the required ATX connectors, and storage drives.

Will my existing SATA SSDs and hard drives work with this B760 board?

Yes, four SATA III ports are available, and a SATA cable is included in the box for immediate connection.
