Eight green DDR4 RDIMM modules with gold contacts and black chips, no heat spreaders

NEMIX RAM

NEMIX RAM 64GB (8x8GB) DDR4 3200 PC4-25600 CL22 288-Pin ECC RDIMM for Tyan Transport SX TS65A-B8036

SKU CH-V72P-G18EG

Eight 8 GB DDR4-3200 ECC registered DIMMs add 64 GB of server-grade memory to a Tyan Transport SX TS65A-B8036

  • Capacity64GB (8 x 8GB)
  • SpeedDDR4 3200 (PC4 25600)
  • ECCYes
  • Buffered/RegisteredRegistered
  • ChipsetMajor OEM Samsung, Micron, Hynix
  • Voltage1.20V
  • 64GB kit expands server capacity for virtualisation workloads
  • ECC registered design protects data integrity in mission-critical systems
  • DDR4 3200 speed matches Tyan Transport SX TS65A-B8036 specifications
  • 2V operation reduces power draw across eight modules
  • 288-pin RDIMM form factor ensures direct compatibility with target motherboard

64 GB DDR4 ECC RDIMM kit for Tyan Transport SX

This 64 GB kit contains eight 8 GB DDR4 3200 registered DIMMs built for the Tyan Transport SX TS65A-B8036. Each module runs at 1.20 V with a CL22 latency and a single-rank 1Rx8 organisation. The registered ECC design targets server and workstation workloads that require error correction.

Registered DDR4 3200 platform constraints

Registered DIMMs add a clock cycle of buffering so the memory controller sees a lighter electrical load. The platform must support registered ECC DDR4 at 3200 MT/s and 1.20 V; consumer boards that accept only unbuffered non-ECC memory will not work with these modules.

Eight-module population requirement

The kit delivers its full 64 GB capacity only when all eight slots are filled with the matched 8 GB sticks. Systems with fewer than eight DDR4 RDIMM slots cannot use the complete kit, and mixing these modules with different capacities or ranks is not supported by the matched specification.

Poudarki

  • 64GB kit expands server capacity for virtualisation workloads
  • ECC registered design protects data integrity in mission-critical systems
  • DDR4 3200 speed matches Tyan Transport SX TS65A-B8036 specifications
  • 2V operation reduces power draw across eight modules
  • 288-pin RDIMM form factor ensures direct compatibility with target motherboard

Specifikacije

BrandNEMIX RAM
SeriesTyan Server/Workstation Motherboard Compatible Series Memory
ModelTyan DDR4 3200MHZ ECC RDIMM Registered Server Memory
Part NumberMR25600-818K8
Capacity64GB (8 x 8GB)
SpeedDDR4 3200 (PC4 25600)
ECCYes
Buffered/RegisteredRegistered
ChipsetMajor OEM Samsung, Micron, Hynix
Voltage1.20V
Compatible SystemTyan
CAS LatencyCL22
Heat SpreaderNo
Type288-Pin DDR4 RDIMM
Rank1Rx8
FeaturesDDR4 ECC Registered RDIMM Server Motherboard Compatible
Package Content64GB (8X8GB) DDR4 3200MHZ PC4-25600 1Rx8 1.2V CL22 288-PIN ECC RDIMM Registered Server Memory KIT

Vprašanja o tem izdelku

Should I pick the 64GB 8x8GB kit or a different capacity for my Tyan Transport SX TS65A-B8036?

The 64GB kit provides eight 8GB modules at DDR4 3200 CL22, filling all slots for maximum registered ECC capacity on the Tyan Transport SX TS65A-B8036.

What does the 3200 MT/s rating deliver once installed in the server?

At 3200 MT/s the modules run at PC4-25600 bandwidth with CL22 latency, giving the Tyan Transport SX TS65A-B8036 its rated DDR4 throughput for registered ECC workloads.

How does the 288-pin RDIMM interface limit speed or capacity in practice?

The 288-pin DDR4 RDIMM interface caps operation at 1.20V and the JEDEC DDR4 3200 standard, so the kit runs at CL22 without overclocking headroom on the Tyan platform.
