Gray 15.6 inch all-in-one PC with capacitive touchscreen and aluminum alloy chassis

partaker

partaker A28 All-in-One PC 15.6" i5-4200U 8GB 128GB Windows 10 Pro

SKU CH-V5T3-3F5SZ

A 15.6" industrial all-in-one PC with a capacitive touchscreen, IP65 front panel, fanless aluminium chassis, Intel Core i5-4200U, 8 GB DDR3, 128 GB storage and Windows 10 Pro

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 4th Gen
  • CPU NameIntel Core i5-4200U

A28 15.6" Capacitive I5 4200U 8GB RAM / 128GB SSD

  • 6" Full HD touch display with 1920x1080 resolution and 400 cd/m² brightness
  • Fanless aluminium chassis runs silently from -20°C to +60°C in harsh environments
  • IP65-rated front panel resists dust and water jets for reliable embedded mounting
  • Dual Gigabit LAN plus 2 COM and 4 USB ports connect industrial equipment directly
  • Intel Core i5-4200U up to 2.60 GHz with 8 GB DDR3 and 128 GB mSATA storage

Industrial All-in-One with 15.6" Touch Screen

The Partaker A28 is a fanless industrial panel PC built around a 15.6 inch Full HD capacitive touchscreen and an Intel Core i5-4200U processor. It ships with 8 GB of DDR3 memory, a 128 GB mSATA SSD and Windows 10 Pro pre-installed. An all-aluminium chassis provides silent, maintenance-free operation in harsh environments.

Suited for embedded automation.

This unit fits buyers who need an IP65-rated front panel, dual Gigabit LAN and legacy serial ports for PLC or scanner integration. It is not for buyers who require a second display output beyond HDMI, internal 2.5 inch drive bays, discrete graphics performance, or a battery-backed mobile form factor.

8 GB memory handles typical HMI and SCADA loads

The board supports up to 16 GB DDR3 across two slots, giving headroom for heavier multi-tasking. The 128 GB mSATA drive covers the OS and local logs, while dual mini-PCIe slots allow cellular or Wi-Fi expansion. Storage and RAM ceilings are reached when datasets exceed the single mSATA capacity or the 16 GB memory limit.

Poudarki

  • 6" Full HD touch display with 1920x1080 resolution and 400 cd/m² brightness
  • Fanless aluminium chassis runs silently from -20°C to +60°C in harsh environments
  • IP65-rated front panel resists dust and water jets for reliable embedded mounting
  • Dual Gigabit LAN plus 2 COM and 4 USB ports connect industrial equipment directly
  • Intel Core i5-4200U up to 2.60 GHz with 8 GB DDR3 and 128 GB mSATA storage

Specifikacije

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 4th Gen
CPU NameIntel Core i5-4200U
Screen Size15.6"
Screen TypeMulti-Touch Screen

Druge različice tega modela

še 5 v isti paleti

Ista družina, različen pomnilnik, hladilnik ali takt — primerjajte, preden se odločite.

Vprašanja o tem izdelku

What external power supply do I need to run the A28?

The unit ships with a 12 V DC input and can also be ordered with a wide-range 9–36 V DC option for industrial power environments.

Can I keep using my RS-232 and RS-485 serial devices with the two COM ports?

Yes, both COM ports are configurable for RS-232 or RS-485 and up to four additional COM ports can be added through the expansion interface.

How can I verify the capacitive touchscreen and fanless cooling are working after installation?

The IP65-rated front panel should respond to multi-touch gestures silently, and the aluminium chassis will remain cool without any fan noise across the -20 to +60 °C operating range.
