Compact 13.3 inch fanless all-in-one PC with IP65 front panel and resistive touchscreen

partaker

partaker A3 13.3" all-in-one PC i5-8265U 16GB DDR4 256GB SSD

SKU CH-ZWXW-1EBB9

A compact 13.3-inch industrial all-in-one with an IP65 front panel, 5-wire resistive touchscreen, Intel Core i5-8265U processor, 16GB DDR4 memory.

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 8th Gen
  • GPU/VGA TypeIntel UHD Graphics
  • Memory Capacity16GB DDR4
  • SSD256GB

Memory Capacity 16GB DDR4

SSD 256GB

HDD None

Prečrtane različice obstajajo, vendar tukaj niso na voljo.

  • IP65 front-panel protection resists dust and water ingress
  • Fanless aluminium chassis runs silently for 24/7 operation
  • 5-wire resistive touchscreen works in high-temperature environments
  • Intel Core i5-8265U up to 3.90 GHz delivers stable industrial performance
  • Windows 11 Pro pre-installed for immediate out-of-the-box use

Compact industrial all-in-one

The Partaker A3 is a 13.3-inch all-in-one panel PC built for continuous industrial use. It ships new with Windows 11 Pro pre-installed and an Intel Core i5-8265U processor. The IP65-rated front panel and 5-wire resistive touchscreen suit harsh environments.

Memory and storage headroom

The unit includes 16GB of DDR4-2400 memory in two SODIMM slots, expandable to 64GB. A 256GB mSATA SSD is fitted; additional M.2 2280 NVME or SATA and 2.5-inch SATA bays allow further capacity. Heavy multi-tasking or large local datasets will need those extra slots.

Silent fanless cooling and power

An aluminium alloy chassis provides passive cooling, so the system runs silently within a 0 to 50°C operating range. Power draw is handled by a 12V DC input from a 100-240V AC adapter. No moving parts means lower maintenance in dusty or vibration-prone settings.

Poudarki

  • IP65 front-panel protection resists dust and water ingress
  • Fanless aluminium chassis runs silently for 24/7 operation
  • 5-wire resistive touchscreen works in high-temperature environments
  • Intel Core i5-8265U up to 3.90 GHz delivers stable industrial performance
  • Windows 11 Pro pre-installed for immediate out-of-the-box use

Specifikacije

ModelA3-PA-133TPC-CE5A(I58)-16G256G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 8th Gen
GPU/VGA TypeIntel UHD Graphics
Memory Capacity16GB DDR4
SSD256GB
HDDNo
Screen Size13.3"
TouchscreenYes

Druge različice tega modela

še 5 v isti paleti

Ista družina, različen pomnilnik, hladilnik ali takt — primerjajte, preden se odločite.

Vprašanja o tem izdelku

Will the A3's 2 x COM ports and VGA output connect directly to my legacy PLCs and older monitors without adapters?

Yes, the unit provides two COM ports and a VGA port alongside two LAN sockets and HDMI, so legacy serial devices and analogue displays plug in natively.

How can I confirm the i5-8265U and 16 GB DDR4 are recognised and the 13.3" resistive touchscreen registers input after first boot?

Open Windows 11 Pro Settings → System → About to verify the processor and 16 GB memory, then tap the screen — the cursor should follow each touch immediately.

Does the box include the 12 V DC power supply and cord, and must I purchase mounting brackets or a Wi-Fi module separately?

The package contains the panel PC, a 100-240 V AC to 12 V DC power supply and a power cord; embedded buckle kits are included for mounting, while a Wi-Fi/4G Mini PCIe card is optional.
