13.3 inch all-in-one panel PC with resistive touchscreen, aluminium fanless chassis, IP65 front

partaker

partaker A3 13.3" all-in-one PC i7-1165G7 8GB 128GB

SKU CH-HRDK-GJSCH

A 13.3" industrial all-in-one PC with IP65 front protection, resistive touchscreen, fanless aluminium cooling, i7-1165G7 processor, 8 GB DDR4 and 128 GB SSD

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 11th Gen
  • GPU/VGA TypeIntel Iris Xe Graphics
  • Memory Capacity8GB DDR4
  • HDDNo

Memory Capacity 8GB DDR4

  • 16GB DDR4
  • 32GB DDR4
  • 8GB DDR4

SSD

HDD None

  • 1TB
  • None

Prečrtane različice obstajajo, vendar tukaj niso na voljo.

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium chassis runs silently 24/7
  • i7-1165G7 up to 4.70 GHz handles heavy workloads
  • 3" resistive touchscreen rated 35 million touches
  • Dual LAN plus four USB and two COM ports

Industrial panel PC for embedded control

The Partaker A3 is a 13.3" all-in-one computer built around an Intel Core i7-1165G7 processor with 8GB of DDR4 memory and a 128GB SSD. Its IP65-rated front panel and five-wire resistive touchscreen are designed for continuous operation in industrial environments where dust, moisture and wide temperature swings are common. The unit ships with Windows 11 Pro installed and supports embedded, wall, desktop or cantilever mounting.

Fanless cooling with 0 to 50°C range

An aluminium alloy chassis provides completely passive cooling, so the system runs silently without moving parts. It is rated for 0 to 50°C operating temperature when used with the installed SSD, drawing power from a 12V DC input that accepts 100 to 240V AC. The 1280 x 800 TFT LED panel reaches 300cd/m² brightness and a 800:1 contrast ratio with 70° horizontal and 55° vertical viewing angles.

Expansion slots for wireless and storage

Two M.2 sockets are provided: a Key E slot for a WIFI6 module and a Key B slot with a SIM tray for 5G connectivity. Internal storage can be expanded via one M.2 2260/2280 PCIe x1 or SATA SSD plus one 2.5" SATA drive bay, while memory can be increased to 64GB across two SODIMM slots. I/O includes HDMI, VGA, dual LAN, two COM ports, two USB 3.0, two USB 2.0 and audio in/out.

Poudarki

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium chassis runs silently 24/7
  • i7-1165G7 up to 4.70 GHz handles heavy workloads
  • 3" resistive touchscreen rated 35 million touches
  • Dual LAN plus four USB and two COM ports

Specifikacije

ModelA3-PA-133TPC-CE5A(I7B)-8G128G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 11th Gen
GPU/VGA TypeIntel Iris Xe Graphics
Memory Capacity8GB DDR4
HDDNo
Screen Size13.3"
TouchscreenYes

Druge različice tega modela

še 5 v isti paleti

Ista družina, različen pomnilnik, hladilnik ali takt — primerjajte, preden se odločite.

Vprašanja o tem izdelku

How do I mount the A3 panel PC in a 326 x 232 mm cut-out and which step is often missed?

Cut the opening to 326 x 232 mm, seat the unit so the IP65 front gasket sits flush, then secure the supplied mounting brackets; the step often missed is torquing the brackets evenly so the seal stays uniform.

Which components will need replacement first in a 24/7 industrial deployment?

The backlight is rated for a minimum of 20,000 hours and the resistive touch layer for 35 million touches; plan to replace the panel or backlight module when brightness drops below usable levels.

What thermal limit appears first when the i7-1165G7 runs sustained loads in a fanless chassis?

The operating ceiling is 50 °C with an SSD installed; once the aluminum chassis saturates, the CPU will throttle to stay within that envelope.
