15 inch IP65 industrial all-in-one with resistive touchscreen and fanless aluminium chassis

partaker

partaker A5 15" IP65 i7-6500U 8GB DDR3 256GB all-in-one PC

SKU CH-R5YV-6TD19

IP65-rated 15" industrial all-in-one with i7-6500U, 8GB DDR3 and 256GB SSD for harsh environments

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 6th Gen
  • GPU/VGA TypeIntel HD Graphics 520
  • Memory Capacity8GB DDR3
  • SSD256GB

Memory Capacity 8GB DDR3

  • IP65 front panel resists dust and water ingress in harsh industrial settings
  • 5-wire resistive touchscreen works reliably at high temperatures and with gloves
  • Intel Core i7-6500U processor delivers strong performance for continuous operation
  • Fanless aluminium alloy cooling runs silently with no moving parts to fail
  • Windows 11 Pro pre-installed for immediate deployment out of the box

Industrial 15" panel PC with IP65 front

The Partaker A5 is a 15-inch all-in-one computer built around an Intel Core i7-6500U processor, 8 GB of DDR3L memory and a 256 GB SSD. Its front panel meets IP65 protection and the resistive touchscreen is rated for high-temperature operation, making the unit suitable for factory floors, kiosks or outdoor enclosures where dust and water ingress are concerns.

Fanless aluminium chassis with embedded mounting

Passive cooling eliminates moving parts, so the system runs silently and avoids fan failure in dirty environments. The chassis measures 354.3 x 278.3 x 54 mm with a 348 x 272 mm cut-out, allowing embedded, wall, desktop or cantilever installation using the supplied buckle kits. I/O includes HDMI, VGA, two USB 3.0, two USB 2.0, dual LAN, audio in/out, two COM ports and a 12 V DC input, while a mini-PCIe slot with SIM holder provides optional wireless expansion.

Sustained 0–50 °C operation with SSD storage

The platform is validated for continuous duty from 0 to 50 °C when equipped with solid-state storage, and 0 to 40 °C with a hard drive. Intel HD Graphics 520 drives the 1024 x 768 TFT LED panel at 350 cd/m² brightness with 1000:1 contrast and 80/80/60/60 viewing angles. The 5-wire resistive touch layer is rated for 35 million touches, and the backlight offers a minimum 30 000-hour life, supporting round-the-clock industrial workloads without thermal throttling.

Poudarki

  • IP65 front panel resists dust and water ingress in harsh industrial settings
  • 5-wire resistive touchscreen works reliably at high temperatures and with gloves
  • Intel Core i7-6500U processor delivers strong performance for continuous operation
  • Fanless aluminium alloy cooling runs silently with no moving parts to fail
  • Windows 11 Pro pre-installed for immediate deployment out of the box

Specifikacije

ModelA5-PA-150TPC-CE5A(I76)-8G256G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 6th Gen
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity8GB DDR3
SSD256GB
HDDNo
Screen Size15"
TouchscreenYes

Druge različice tega modela

še 5 v isti paleti

Ista družina, različen pomnilnik, hladilnik ali takt — primerjajte, preden se odločite.

Vprašanja o tem izdelku

What is the maximum operating temperature before the fanless cooling reaches its limit?

The fanless aluminium chassis is rated for continuous operation up to 50 °C with an SSD installed, or up to 40 °C if a 2.5" hard drive is used instead.

How much heat and noise does the passive cooler produce during 24/7 operation?

The fanless design generates no audible noise; the aluminium alloy case acts as a heatsink, so surface temperature rises with load but stays within the 0–50 °C operating window.

Which power supply must already be on site for the unit to start?

A 12 V DC source is required; the box includes a 100–240 V AC to 12 V DC adapter and power cord for standard mains connection.
