Green PCIe x1 card with one USB-C and one USB-A port on the metal bracket, a 20-pin internal header and a SATA power connector

EN-Labs

EN-Labs PCIEU3ACS20 PCIe USB 3.2 expansion card

SKU CH-ZGYR-4A4R5

Adds four USB 3.2 Gen 1 ports — one Type-C, one Type-A and a 20-pin internal header — via a PCIe x1 slot with SATA power

  • TypePCI Express to USB Card
  • Internal USB Ports4x USB Ports
  • External PortsUSB 3.2 Type-C + USB type-A (5Gbps)
  • Internal PortsUSB 3.0 20pin
  • StandardUSB 3.2 Gen 1
  • Data Transfer RateUp to 5.0 Gbps
  • Adds four USB 3.2 ports via a single PCIe slot
  • 0 Gbps transfer speed for fast external storage
  • USB Type-C and Type-A ports on the rear bracket
  • 20-pin internal header connects two front-panel USB ports
  • SATA power connector ensures stable supply for all ports

PCIe USB 3.2 expansion card

The EN-Labs PCIEU3ACS20 adds four USB 3.2 Gen 1 ports through a single PCI Express x1 slot. It provides one USB Type-C and one USB Type-A port on the rear bracket plus a 20-pin internal header for two front-panel ports. The card fits both full-profile and low-profile brackets.

5 Gbps data rate and SATA power

The card delivers up to 5.0 Gbps per port via a Renesas uPD720201 controller and is backward compatible with USB 2.0 and 1.1 devices. It draws auxiliary power from a 15-pin SATA connector supplied by the system PSU.

Low thermal load in typical use

The x1 PCIe interface and SATA power supply keep power draw modest during normal file transfers and peripheral connections. No active cooling is fitted and the card runs silently in standard desktop workloads.

Fordele

  • Adds four USB 3.2 ports via a single PCIe slot
  • 0 Gbps transfer speed for fast external storage
  • USB Type-C and Type-A ports on the rear bracket
  • 20-pin internal header connects two front-panel USB ports
  • SATA power connector ensures stable supply for all ports

Specifikationer

BrandEn-Labs
ModelPCIEU3ACS20
TypePCI Express to USB Card
Internal USB Ports4x USB Ports
External PortsUSB 3.2 Type-C + USB type-A (5Gbps)
Internal PortsUSB 3.0 20pin
StandardUSB 3.2 Gen 1
Data Transfer RateUp to 5.0 Gbps
FeaturesAdd 4 USB 3.0 ports(1 x USB Type-C+1 x Type A + 20 Pin Internal) through a PCI Express slot Compatible with PCI-Express 2.0 standard Compatible with Super Speed USB 3.2 GEN 1 (5Gbps) standard, backwards to USB 2.0 and USB 1.1 Maximum transfer speed: 5Gbps Power by SATA 15pin Supports PCIe 1x, 4x, 8x, 16x Slot Support Windows XP / 2003 / Win7 / Win8 / Vista / Linux
Package Contents1 x PCIe USB Type-C PCI express card 1 x Driver CD

Spørgsmål om denne vare

What does the 5 Gbps USB 3.2 Gen 1 rating deliver in a real PC?

Each of the four ports can reach up to 5 Gbps, shared across the single PCIe x1 link; actual throughput depends on the host controller and connected devices.

Which PCI Express standard does the card use and what bandwidth does that limit?

The card fits PCIe 2.0 x1 and works in x1, x4, x8 or x16 slots, capping the total upstream bandwidth to the PCIe 2.0 single-lane rate.

What bracket and power connections are needed to install the card?

Both full-height and low-profile brackets are included; a 15-pin SATA power connector from the PSU is required for operation.
