Green circuit board with MiniPCIe slot, RJ45 jack, two USB ports and 16-pin cable connector

LORDWORLD

LORDWORLD PCIe to MiniPCIe HAT for Raspberry Pi 5

SKU CH-FZ72-YW22V

A HAT adding MiniPCIe, Gigabit Ethernet and two USB 3.2 Gen1 ports to Raspberry Pi 5 via 16-pin cable for 4G modules and positioning

  • Driver-free plug-and-play setup on Raspberry Pi 5
  • MiniPCIe slot accepts SIM7600G-H-PCIE and EG25-G-mPCIe 4G modules
  • Direct 16-pin PCIe link to Pi 5 for stable throughput
  • Two USB 3.2 Gen1 ports add high-speed peripheral connectivity
  • Multi-constellation GNSS plus LBS positioning for accurate location data

PCIe to MiniPCIe HAT for Pi 5

The LORDWORLD HAT connects to the Raspberry Pi 5 through a 16-pin PCIe cable and adds a MiniPCIe slot, a Gigabit Ethernet port and two USB 3.2 Gen1 ports. It is aimed at makers and developers who need cellular connectivity and extra high-speed peripherals on a single board.

Upgrading from USB-only dongles

Moving from a USB 4G stick to this HAT removes the USB bottleneck and frees the Pi 5's native USB ports for other devices. The jump is worth it when you need simultaneous Gigabit wired networking, dual USB 3.2 Gen1 peripherals and a MiniPCIe module such as the SIM7600G-H-PCIE or EG25-G-mPCIe series without driver installation.

Check your setup before ordering

Verify that your project can accommodate the HAT's physical footprint and that you have a 16-pin PCIe cable for the Pi 5 connection. Ensure the target MiniPCIe module matches the supported SIM7600G-H-PCIE or EG25-G-mPCIe series and confirm your operating system is Raspberry Pi OS, Ubuntu or OpenWRT for plug-and-play operation.

Fordele

  • Driver-free plug-and-play setup on Raspberry Pi 5
  • MiniPCIe slot accepts SIM7600G-H-PCIE and EG25-G-mPCIe 4G modules
  • Direct 16-pin PCIe link to Pi 5 for stable throughput
  • Two USB 3.2 Gen1 ports add high-speed peripheral connectivity
  • Multi-constellation GNSS plus LBS positioning for accurate location data

Specifikationer

BrandLORDWORLD

Spørgsmål om denne vare

What clearance does the 16-pin PCIe cable need between the HAT and the Raspberry Pi 5?

The HAT connects to the Pi 5 through a 16-pin PCIe cable, so allow enough vertical space for the cable bend radius and the MiniPCIe module height above the board.

Which step is most often missed when fitting a SIM7600G-H-PCIE or EG25-G-mPCIe module into the onboard MiniPCIe slot?

Insert the 4G module at an angle, press down until the retaining clips click, then secure the screw before attaching the 16-pin cable to the Pi 5.

When should the MiniPCIe 4G module or its antenna cables be replaced?

Replace the module if it no longer registers on 4G networks or GPS, BeiDou, Glonass, GALILEO, QZSS and LBS positioning fails; swap antenna cables if signal strength drops permanently.
