Silver rectangular servo motor with black output horn and side cable connector

LORDWORLD

LORDWORLD SC15 17kg Serial Bus Servo 253 Units 8.4V

SKU CH-0GW0-EHSN1

A serial bus servo delivering 17kg·cm torque at 8.4V with real-time position, load, speed and voltage feedback, supporting up to 253 units in series for multi-servo robots

  • Control up to 253 servos on one serial bus
  • Delivers 17 kg·cm torque at 8.4 V
  • Real-time position, load, speed and voltage feedback
  • Switch between servo and motor operating modes
  • Precise rotation angle control in servo mode

LORDWORLD SC15 17kg Serial Servo

The LORDWORLD SC15 is a programmable serial bus servo delivering up to 17kg.cm torque at 8.4V. It accepts UART commands that let up to 253 units operate on a single bus. Two-way feedback reports position, load, speed and input voltage in real time. Dual modes allow precise angle control or continuous rotation.

Makers building multi-servo robots

This servo suits builders of quadrupeds, hexapods or robotic arms that need many coordinated joints on one serial line. Real-time telemetry helps closed-loop gait code. Projects that require PWM-only control, lower voltage logic or a single standalone actuator should look at something else.

Check bus voltage and connector wiring

Verify your controller can supply 8.4V to the bus and that its UART pins match the servo connector pinout. Confirm the firmware library supports the feedback protocol for position, load, speed and voltage. Ensure mechanical mounting points align with the horn pattern used in your design.

Fordele

  • Control up to 253 servos on one serial bus
  • Delivers 17 kg·cm torque at 8.4 V
  • Real-time position, load, speed and voltage feedback
  • Switch between servo and motor operating modes
  • Precise rotation angle control in servo mode

Specifikationer

BrandLORDWORLD

Spørgsmål om denne vare

What controller or bus do I need to connect up to 253 SC15 servos in series?

You need a UART serial bus controller that can address each servo individually on the shared line.

Can I mix the SC15 with older servos that use a different protocol on the same bus?

No, the SC15 uses a UART serial bus; older PWM or analogue servos cannot share the same line.

How do I confirm the SC15 is delivering up to 17 kg·cm torque at 8.4 V after installation?

Read the real-time load and voltage feedback over the serial bus while the servo is under load.
