White rack-mountable gateway with 1.3 inch touchscreen and front port array

Ubiquiti Networks

Ubiquiti Dream Machine Special Edition 10G firewall appliance UDM-SE 180W

SKU CH-QWN9-A7J4N

Rack-mountable 10 GbE cloud gateway with 3.5 Gbps IDS/IPS throughput, integrated PoE switching, 128 GB SSD storage, and 1.3" touchscreen for managing 100+ UniFi devices

  • Form FactorRack Mountable
  • Speed10GbE
  • ProcessorQuad-core ARM Cortex-A57 at 1.7 GHz
  • System Memory4 GB DDR4 16 GB eMMC Integrated 128 GB SSD
  • Display Size1.3" touchscreen
  • Ports8 x 1GbE RJ45, 1 x 2.5GbE RJ45, 2 x 10G SFP+

Model Dream Machine Special Edition

Vis 1 flere konfigurationer
  • Dream Machine Beast

De overstregede versioner findes, men er ikke på lager her.

  • 10 Gbps SFP+ and 2.5 Gbps WAN for high-speed uplinks
  • 5 Gbps IDS/IPS throughput inspects traffic at line rate
  • Eight 1 GbE LAN ports with six PoE and two PoE+ power devices
  • Built-in 128 GB SSD plus 3.5" bay stores NVR footage locally
  • 3" touchscreen gives instant status without a separate monitor

10G Cloud Gateway with PoE

The Ubiquiti Dream Machine Special Edition is a rack-mountable firewall appliance built for small to medium networks that need integrated switching and routing. It combines a quad-core ARM Cortex-A57 processor at 1.7 GHz with 4 GB of DDR4 memory and 16 GB eMMC storage. The unit includes a 128 GB SSD for NVR recordings and a 1.3 inch touchscreen for local status.

3.5 Gbps IDS/IPS throughput limit

The appliance delivers 3.5 Gbps of routing performance with intrusion detection and prevention enabled. It provides one 10G SFP+ and one 2.5GbE RJ45 WAN port alongside eight 1GbE LAN ports, six of which supply PoE and two PoE+. Total simultaneous sessions are capped at 1000, and the operating temperature range spans -10 to 40° C.

100 UniFi devices and 1000 clients

The gateway comfortably manages over 100 UniFi access points, switches or cameras while supporting more than 1000 connected clients. The 3.5 inch NVR drive bay adds local video storage capacity beyond the built-in 128 GB SSD. Networks requiring 5 Gbps IDS/IPS throughput or 2000 simultaneous users exceed the capabilities of this model.

Fordele

  • 10 Gbps SFP+ and 2.5 Gbps WAN for high-speed uplinks
  • 5 Gbps IDS/IPS throughput inspects traffic at line rate
  • Eight 1 GbE LAN ports with six PoE and two PoE+ power devices
  • Built-in 128 GB SSD plus 3.5" bay stores NVR footage locally
  • 3" touchscreen gives instant status without a separate monitor

Specifikationer

BrandUbiquiti Networks
SeriesGateway
ModelDream Machine Special Edition
Part NumberUDM-SE (180W)
Form FactorRack Mountable
Speed10GbE
ProcessorQuad-core ARM Cortex-A57 at 1.7 GHz
System Memory4 GB DDR4
16 GB eMMC
Integrated 128 GB SSD
Display Size1.3" touchscreen
Ports8 x 1GbE RJ45, 1 x 2.5GbE RJ45, 2 x 10G SFP+
Simultaneous Sessions1000
WAN Ports1 x 10Gbps, 1 x 2.5Gbps
LAN Ports1 x 10Gbps, 8 x 1Gbps
LEDsEthernet: White: link/activity
SFP+: White: link/activity
HDD: White: disk activity
Amber: disk error
RPS: Blue: ready
VPNWireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
Throughput3.5 Gbps
PoE Interface(6) PoE (Pair A 1, 2+; 3, 6-)
(2) PoE+ (Pair A 1, 2+; 3, 6-)
ButtonFactory reset
Temperature-10 to 40° C (14 to 104° F)
Humidity5 to 95% noncondensing
CertificationsCE, FCC, IC
Power Input(1) Universal AC input, 100-240V AC, 4.4A Max., 50/60 Hz
(1) USP-RPS DC input, 52V DC, 3.94A
Max Power Consumption240W, 180W PoE budget
FeaturesGateway Features
Performance:
- Redundant WAN with failover and load balancing
- WiFi QoS with UniFi APs
- Application, domain, and country-based QoS
- Application and device type identification
- Additional internet failover with LTE Backup
- Internet quality and outage reporting
Next-generation security
- Application-aware firewall rules
- Signature-based IPS/IDS threat detection
- Content, country, domain, and ad filtering
- VLAN/subnet-based traffic segmentation
- Full stateful firewall
Advanced networking
- License-free SD-WAN
- WireGuard, L2TP and OpenVPN server
- OpenVPN clien
Dimensions442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
Weight5 kg (10.9 lbs.)
Forsendelsesvægt5.65 kg
Pakkestørrelse518 × 414 × 119 mm

Andre versioner af denne model

3 flere i samme serie

Samme familie, men med anden hukommelse, køler eller clockfrekvens — sammenlign, før du bestemmer dig.

Spørgsmål om denne vare

Should I choose the Dream Machine Special Edition or the Pro Max for my network size?

The Special Edition supports up to 100 managed UniFi devices and 1,000 simultaneous users, while the Pro Max doubles that to 200+ devices and 2,000+ users.

What does the 3.5 Gbps throughput figure mean when the appliance is inspecting traffic?

With IDS/IPS enabled, the unit routes and inspects at 3.5 Gbps; without inspection it can pass 10 Gbps.

How do the 10G SFP+ and 2.5GbE WAN ports limit my uplink speed?

You can connect a 10 Gbps fibre link on the SFP+ port or a 2.5 Gbps copper link on the RJ45 port; the slower port caps at 2.5 Gbps.
