White 120mm square case fan with centre ARGB lighting and 4-pin connector

YESTON

YESTON Zeaginal ZC-ZHUISHEN White LED 120mm Case Fan

SKU CH-2Q6F-01Q8V

120 mm PWM case fan with hydraulic bearing, 68 CFM airflow, 2.4 mmH₂O pressure and 32 dBA noise at up to 1850 RPM

  • Fan Counts1 Fan
  • TypeCase Fan
  • Fan Thickness25mm
  • Bearing TypeHydraulic
  • RPM900~1850RPM±10%
  • Air Flow68CFM
  • Quiet cooling with 32 dBA noise level
  • High airflow delivering 68 CFM
  • Strong static pressure of 2.4 mmH₂O
  • Wide PWM speed range 900–1850 RPM
  • ARGB lighting with AURA SYNC support

White LED Case Fan for PC Builds

The YESTON Zeaginal ZC-ZHUISHEN is a single 120mm case fan designed for system cooling in desktop computers. It uses a hydraulic bearing and a 4-pin PWM connector for automatic speed control. White ARGB lighting with AURA SYNC support adds visual coordination for themed builds. It suits builders who want a balance of airflow and illumination.

Thermals Noise and Power Draw

The fan spins between 900 and 1850 RPM with a tolerance of ten percent. At maximum speed it delivers 68 CFM of airflow and 2.4 mmH2O of static pressure while producing 32 dBA of noise. The motor runs on 12 V DC and the LEDs draw power from a separate 5 V DC line. The 25 mm thickness fits standard mounting points.

Upgrade Path and Fit

This unit replaces a worn or missing 120mm fan in a case, CPU cooler or radiator. The hydraulic bearing offers longer life than sleeve alternatives and the PWM curve lets the motherboard tune speed to temperature. Builders who need higher static pressure for dense radiators or who prefer a non-LED fan should look elsewhere.

Kohokohdat

  • Quiet cooling with 32 dBA noise level
  • High airflow delivering 68 CFM
  • Strong static pressure of 2.4 mmH₂O
  • Wide PWM speed range 900–1850 RPM
  • ARGB lighting with AURA SYNC support

Tekniset tiedot

BrandYeston
SeriesZeaginal ZC-ZHUISHEN
Fan Counts1 Fan
TypeCase Fan
Fan Thickness25mm
Bearing TypeHydraulic
RPM900~1850RPM±10%
Air Flow68CFM
Air Pressure2.4mmH20
Noise Level32dBA
Power Connector4 Pin
ColorWhite
LEDARGB
Dimensions120x120x25mm

Kysymyksiä tästä tuotteesta

How do I connect the 4-pin PWM and 5 V ARGB cables so the fan spins and the white LEDs sync with AURA SYNC?

Plug the 4-pin PWM connector into a motherboard fan header for 900–1850 RPM control and the 3-pin 5 V ARGB header into the matching motherboard RGB header; the white LEDs will then sync via AURA SYNC.

When should I expect the hydraulic bearing to need replacement under continuous 1850 RPM operation?

Hydraulic bearings typically run for years at 32 dBA and 68 CFM; listen for rising noise or vibration as the first sign the bearing is wearing.

At what point does the 2.4 mmH₂O static pressure become the limiting factor during sustained high-RPM use?

When airflow meets dense radiator fins or restrictive filters, the 2.4 mmH₂O pressure caps effective cooling before the 1850 RPM ceiling is reached.
