Black-and-white PTZ bullet camera with bracket, 10× zoom lens, IP66 housing, BNC connector, 12 V power input

DiySecurityCameraWorld

DiySecurityCameraWorld CVI-SCB415CI-V10 2MP 10X PTZ Bullet 5.1-51mm IP66 12V

SKU CH-04B3-N4H9X

A 2MP CVI PTZ bullet camera with 10x optical zoom, 5.1-51mm lens, 80m IR night vision and IP66 weatherproof housing for outdoor surveillance

  • ColorBlack / White
  • Network CameraNo
  • Camera Type2 Megapixel
  • Type1080P CVI PTZ Bullet Camera
  • Connection TypeBNC
  • Sensor & DetectorCMOS
  • 10x optical zoom covers wide to telephoto with 5.1-51mm lens
  • 1080p HD-CVI delivers crisp 1920x1080 video at 30fps
  • IR night vision reaches up to 80 metres for 24/7 monitoring
  • IP66-rated metal housing withstands extreme outdoor conditions
  • Remote pan 0-250° and tilt -5° to -55° via PC software

What this camera is and who it serves

The DiySecurityCameraWorld CVI-SCB415CI-V10 is a 2MP HD-CVI PTZ bullet camera with a 10X optical zoom lens spanning 5.1-51mm. It connects via BNC and requires a compatible 1080P HD-CVI DVR to operate. The unit is built for outdoor installation with an IP66-rated metal housing and includes a mounting bracket, screws and a user manual.

Behaviour under sustained outdoor use

The camera delivers 1080p video at 30fps through a 1/3" CMOS sensor and supports pan rotation up to 250° and tilt from -5° to -55°. Pan speed ranges from 0.5°/s to 15°/s while tilt speed runs from 0.5°/s to 10°/s. Four high-power array LEDs provide infrared illumination up to 80 metres for continuous night surveillance. The IP66 enclosure protects against dust and heavy rain during extended deployment.

What to verify before ordering

Confirm your DVR supports 1080P HD-CVI signals over BNC, as this camera will not work with other analog formats or IP recorders. Ensure a 12VDC 2A power supply is available because no adapter is included in the package. Check that the mounting location can accommodate the bracket and allows the required pan and tilt ranges without obstruction.

נקודות עיקריות

  • 10x optical zoom covers wide to telephoto with 5.1-51mm lens
  • 1080p HD-CVI delivers crisp 1920x1080 video at 30fps
  • IR night vision reaches up to 80 metres for 24/7 monitoring
  • IP66-rated metal housing withstands extreme outdoor conditions
  • Remote pan 0-250° and tilt -5° to -55° via PC software

מפרט טכני

BrandDiySecurityCameraWorld
ModelCVI-SCB415CI-V10
ColorBlack / White
Network CameraNo
Camera Type2 Megapixel
Type1080P CVI PTZ Bullet Camera
Connection TypeBNC
Sensor & DetectorCMOS
MAX Resolution1920 x 1080
Video Capture Resolution1080P
Frame Rate30fps
Lens Type10X optical zoom Lens
Night VisionYes
PowerDC 12V

שאלות על הפריט הזה

Does the 10X optical zoom lens run silently when the camera pans and tilts all day?

The pan speed ranges from 0.5 to 15 degrees per second and the tilt speed from 0.5 to 10 degrees per second, so motor noise is low during continuous operation.

What must I already own for this BNC-output camera to record video?

You need a 1080P HD-CVI compatible DVR because the camera transmits analogue HD-CVI over coaxial cable and cannot connect directly to a network or recorder of another type.

Can I mix this 2MP CVI PTZ with older analogue cameras on the same DVR?

Yes, provided the DVR supports HD-CVI at 1080P, it will accept the 1920x1080 signal alongside standard-definition analogue channels on the remaining BNC inputs.
