17 inch IP65 resistive touch all-in-one PC aluminium fanless chassis

partaker

partaker A9 17" IP65 resistive touch all-in-one PC i7-6500U 16GB DDR3 512GB SSD

SKU CH-AK52-YMJPP

A 17-inch IP65 resistive-touch all-in-one PC with an i7-6500U, 16GB DDR3 and 512GB SSD for continuous industrial use

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 6th Gen
  • GPU/VGA TypeIntel HD Graphics 520
  • Memory Capacity16GB DDR3
  • SSD512GB

Memory Capacity 16GB DDR3

  • IP65 front panel resists dust and water jets
  • 5-wire resistive touchscreen works with gloves or stylus
  • Intel Core i7-6500U up to 3.10 GHz for continuous 24/7 operation
  • Fanless aluminium alloy chassis runs silently without moving parts
  • Windows 11 Pro pre-installed for immediate deployment

Industrial 17-inch panel PC

The Partaker A9 is a 17-inch all-in-one computer with an IP65-rated front panel and a five-wire resistive touchscreen. It runs on an Intel Core i7-6500U processor with 16GB of DDR3 memory and a 512GB SSD. The fanless aluminium chassis is built for continuous operation in industrial settings. Windows 11 Pro comes pre-installed for immediate deployment.

Check power and peripheral fit

Verify that your site can supply 12V DC power via the included AC adapter, which accepts 100-240V input. Confirm the panel cut-out matches the 380mm by 315mm opening hole dimensions for embedded mounting. Ensure any expansion cards use the mini PCIe slot and that serial devices match the two COM ports provided. The unit has two LAN ports, HDMI, VGA, audio I/O, two USB 3.0 and two USB 2.0 ports.

Fanless build and mounting flexibility

The passive aluminium cooling system runs silently without moving parts, reducing maintenance in dusty or vibration-prone areas. An operating range of 0 to 50°C with the SSD installed suits harsh environments. Mounting buckle kits support embedded, wall, desktop or cantilever installation. The resistive touchscreen works with gloves and offers 35 million touch cycles. Rear I/O faces downward for cable routing in tight cabinets.

נקודות עיקריות

  • IP65 front panel resists dust and water jets
  • 5-wire resistive touchscreen works with gloves or stylus
  • Intel Core i7-6500U up to 3.10 GHz for continuous 24/7 operation
  • Fanless aluminium alloy chassis runs silently without moving parts
  • Windows 11 Pro pre-installed for immediate deployment

מפרט טכני

ModelA9-PA-170TPC-CE5A(I76)-16G512G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 6th Gen
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity16GB DDR3
SSD512GB
HDDNo
Screen Size17"
TouchscreenYes

גרסאות נוספות של דגם זה

5 נוספים באותה הסדרה

אותה משפחה, זיכרון, קירור או תדר שונים — השווה לפני שתחליט.

שאלות על הפריט הזה

Does the box include the power supply and cord, or must they be purchased separately?

The packing list includes the Partaker A9 panel PC, a power supply and a power cord, so no separate purchase is needed for basic operation.

Should I choose the mSATA, M.2 2280 or 2.5-inch bay for additional storage?

The 512 GB SSD is already installed; the M.2 2280 slot supports NVMe or SATA, the mSATA slot takes SATA only, and the 2.5-inch bay accepts SATA SSD or HDD.

What does the 3.10 GHz turbo figure mean when the PC is running a continuous industrial workload?

The i7-6500U can reach 3.10 GHz on short bursts, but the fanless aluminium chassis relies on passive cooling, so sustained clocks will settle lower during 7×24 operation.
