14 inch black all-in-one industrial panel PC with IP65 touchscreen

partaker

Partaker Z10-I7 1165G7-32G512G all-in-one PC

SKU CH-QCW3-K9VMN

A 14-inch IP65 all-in-one with 10-point capacitive touch, Core i7-1165G7, 32GB DDR4, 512GB SSD, dual LAN, HDMI, VGA, dual COM, WiFi 6 and 5G expansion slots, fanless aluminium chassis.

  • Form FactorAll-in-One
  • ColorBlack
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 11th Gen
  • CPU NameIntel Core i7-1165G7
  • GPU/VGA TypeIntel Iris Xe Graphics

CPU Type Intel Core i7 11th Gen

CPU Name Intel Core i7-1165G7

GPU Intel Iris Xe Graphics

Memory 32GB DDR4

SSD 512GB

  • 256GB
  • 512GB
  • 1TB
  • 128GB

Preškrtnuté verzie existujú, ale nie sú tu skladom.

  • IP65 front-panel protection resists dust and water jets in harsh environments
  • Intel Core i7-1165G7 quad-core CPU up to 4.7 GHz handles demanding industrial workloads
  • 32 GB DDR4-3200 memory and 512 GB SSD provide fast, responsive multitasking
  • 14-inch 10-point projected capacitive touchscreen rated for 200 million touches
  • Fanless aluminium chassis operates silently from 0 to 50 °C with SSD

Industrial all-in-one with IP65 front panel

The Partaker Z10-I7 1165G7-32G512G is a 14-inch fanless panel PC built around an Intel Core i7-1165G7 processor and Intel Iris Xe Graphics. It ships with Windows 11 Pro, 32GB of DDR4-3200 memory and a 512GB SSD. The aluminium chassis carries an IP65 rating on the front bezel and operates from 0 to 50°C, making it suitable for embedded, wall-mounted or desktop installation in harsh commercial environments.

32GB DDR4 and 512GB SSD with dual drive bays

The system includes two SODIMM slots supporting up to 64GB of DDR4-3200 RAM, so the fitted 32GB leaves headroom for memory-intensive workloads. Storage uses one M.2 2260/2280 slot (PCIe x1 or SATA) occupied by the 512GB drive, plus a spare 2.5-inch SATA bay for a second SSD or HDD. When the second bay is filled with a hard drive the operating range narrows to 0–40°C, while SSD-only configurations retain the full 0–50°C envelope.

Expansion slots for 5G and WiFi 6 plus legacy I/O

Two internal M.2 sockets are provided: a Key E slot for a WiFi 6 module and a Key B slot with a SIM holder for 5G connectivity, both unused as shipped. External I/O covers dual LAN, HDMI, VGA, two USB 3.0, two USB 2.0, audio in/out and two COM ports, plus a 12V DC jack. The package includes a 100–240V AC power adapter and mounting hardware for the four supported installation methods. Buyers who need out-of-the-box wireless connectivity must add the modules themselves.

Prednosti

  • IP65 front-panel protection resists dust and water jets in harsh environments
  • Intel Core i7-1165G7 quad-core CPU up to 4.7 GHz handles demanding industrial workloads
  • 32 GB DDR4-3200 memory and 512 GB SSD provide fast, responsive multitasking
  • 14-inch 10-point projected capacitive touchscreen rated for 200 million touches
  • Fanless aluminium chassis operates silently from 0 to 50 °C with SSD

Špecifikácie

ModelZ10-I7 1165G7-32G512G
Form FactorAll-in-One
ColorBlack
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 11th Gen
CPU NameIntel Core i7-1165G7
GPU/VGA TypeIntel Iris Xe Graphics
Memory Capacity32GB DDR4
SSD512GB
HDDNo
Screen Size14"
TouchscreenYes

Ďalšie verzie tohto modelu

Ďalších 5 v tomto rade

Rovnaký rad, iná pamäť, chladič alebo frekvencia — porovnajte pred rozhodnutím.

Otázky k tomuto produktu

Will the VGA and HDMI ports on this Z10 let me keep using my older monitors alongside the built-in 14-inch 1600x900 touchscreen?

Yes, the Z10 provides both VGA and HDMI outputs so you can drive legacy displays while the internal 14-inch panel runs at 1600x900.

After powering on, what indicates the fanless cooling and IP65 front panel are functioning correctly?

The unit runs silently with no fan noise, the 10-point capacitive touchscreen responds immediately, and the chassis stays within the 0–50°C operating range under load.

Does the package include the 12 V power adapter and mounting hardware, or must I source the M.2 WiFi 6 or 5G modules separately?

The box contains the Z10 panel PC, a 100-240 V AC to 12 V DC adapter, and mounting kits; WiFi 6 (M.2 Key E) and 5G (M.2 Key B with SIM slot) modules are optional extras.
