MSI
MSI B250M G1 GAMER B250 LGA 1151 DDR4 32GB Micro ATX motherboard
Micro-ATX board for 6th/7th gen Intel CPUs with DDR4 memory up to 32GB, PCIe 3.0 slots, six SATA ports, 7.1 audio and Gigabit LAN
- CPU Socket TypeLGA 1151
- CPU TypeSupports 6th/7th generation Intel Core i3/i5/i7 processors,
- ChipsetIntel B250
- Memory StandardSupports dual-channel DDR4 2400/2133MHz memory
- Maximum Memory Supported32GB
- PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 3.0 x1 slots
- Supports 6th and 7th generation Intel Core i3 i5 i7 processors with LGA 1151 socket
- Dual channel DDR4 memory up to 32GB at 2400 and 2133MHz
- One PCIe 3.0 x16 slot plus two PCIe 3.0 x1 slots for expansion
- Realtek ALC887 audio codec delivers 7.1 channel high definition sound
- Realtek RTL8111H Gigabit LAN with six USB 3.1 Gen1 and six USB 2.0 ports
Socket LGA 1151 Micro ATX board
This MSI B250M G1 GAMER motherboard uses the Intel B250 chipset and fits LGA 1151 processors from the 6th and 7th generation Core i3, i5 and i7 families plus Pentium and Celeron parts. The Micro ATX form factor suits compact builds that still need dual-channel DDR4 memory up to 32GB at 2400 or 2133MHz.
Bundled I/O shield and single SATA cable
The box supplies a chassis I/O back panel, one SATA cable and a CMOS battery so the board can be mounted and connected to a drive immediately. No extra USB brackets, Wi-Fi antennas or additional cables are provided unless the board itself includes an onboard Wi-Fi module.
Standard Micro ATX mounting
Installation follows the usual Micro ATX screw pattern and uses the supplied I/O shield; the single PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots accept common expansion cards. The six SATA III ports and one M.2 interface share bandwidth, so populating every SATA connector can disable the M.2 slot — check the manual before adding drives.
Přednosti
- Supports 6th and 7th generation Intel Core i3 i5 i7 processors with LGA 1151 socket
- Dual channel DDR4 memory up to 32GB at 2400 and 2133MHz
- One PCIe 3.0 x16 slot plus two PCIe 3.0 x1 slots for expansion
- Realtek ALC887 audio codec delivers 7.1 channel high definition sound
- Realtek RTL8111H Gigabit LAN with six USB 3.1 Gen1 and six USB 2.0 ports
Specifikace
| Brand | MSI |
|---|---|
| Series | MSI B250M G1 GAMER |
| Model | MSI B250M G1 GAMER |
| CPU Socket Type | LGA 1151 |
| CPU Type | Supports 6th/7th generation Intel Core i3/i5/i7 processors, as well as Intel Pentium and Celeron processors with pin LGA1151 |
| Chipset | Intel B250 |
| Memory Standard | Supports dual-channel DDR4 2400/2133MHz memory |
| Maximum Memory Supported | 32GB |
| PCI Slots | 1 PCIe 3.0 x16 slot 2 PCIe 3.0 x1 slots |
| SATA RAID | 1XM.2 interface, 6xSATA III interface |
| Audio Chipset | Realtek ALC887 decoding chip - 7.1 channel high-quality sound effects |
| LAN Chipset | 1 x Realtek RTL8111H Gigabit network interface card |
| Onboard USB | - 6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the backplane, 2 via onboard USB ports) - 6 USB 2.0 (High-speed USB) ports (2 ports on the backplane, 4 via onboard USB ports) |
Otázky k tomuto produktu
Will the CMOS battery need replacing during the board's life?
The board ships with a replaceable CMOS battery that maintains BIOS settings when the system is unplugged.
What limits the maximum memory I can install on this B250 board?
Two DDR4 slots support up to 32 GB total at 2400 or 2133 MHz in dual-channel mode.
How hot or loud does the chipset area get under all-day loads?
The B250 chipset runs passively cooled; typical case airflow keeps it quiet and within normal operating temperatures.
