Compact 12.1 inch industrial all-in-one panel PC with IP65 front touchscreen and fanless aluminum chassis

partaker

partaker A1-PA-121TPC-CE6B(I76)-8G512G all-in-one PC i7-6500U 8GB DDR3 512GB 12.1" IP65

SKU CH-Q5KV-C8R95

A 12.1-inch IP65-rated industrial all-in-one PC with a 10-point capacitive touchscreen, Intel Core i7-6500U, 8 GB DDR3 memory and a 512 GB SSD

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 6th Gen
  • GPU/VGA TypeIntel HD Graphics 520
  • Memory Capacity8GB DDR3
  • SSD512GB

Memory Capacity 8GB DDR3

  • IP65 front panel resists dust and water ingress
  • 10-point projected capacitive touch enables precise multi-touch control
  • Intel Core i7-6500U delivers up to 3.10 GHz for demanding tasks
  • Fanless aluminium alloy cooling runs silently and reliably
  • Windows 11 Pro 64-bit provides a modern, secure OS environment

Industrial panel PC with IP65 front

This 12.1 inch all-in-one computer integrates an Intel Core i7 6500U processor, 8GB DDR3L memory and a 512GB SSD behind a projected capacitive touchscreen. The fanless aluminium chassis is rated for continuous operation in industrial environments and ships with Windows 11 Pro 64-bit installed.

Fanless aluminium build and versatile I/O

Passive cooling eliminates moving parts and noise while the IP65 front panel resists dust and water jets. Connectivity includes HDMI, VGA, two USB 3.0, two USB 2.0, dual LAN, audio in/out, two COM ports and a 12V DC input, supporting embedded, wall, desktop or cantilever mounting with a 301 by 229mm cut-out.

Upgrades legacy panel PCs needing modern OS

The system replaces older fixed-function terminals that lack 10-point touch, current OS support or silent operation. The jump is worthwhile when an application requires Windows 11 Pro, projected capacitive input and fanless reliability in a 12.1 inch form factor; it is not suited for buyers who need larger screens, higher brightness or expandable discrete graphics.

Přednosti

  • IP65 front panel resists dust and water ingress
  • 10-point projected capacitive touch enables precise multi-touch control
  • Intel Core i7-6500U delivers up to 3.10 GHz for demanding tasks
  • Fanless aluminium alloy cooling runs silently and reliably
  • Windows 11 Pro 64-bit provides a modern, secure OS environment

Specifikace

ModelA1-PA-121TPC-CE6B(I76)-8G512G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 6th Gen
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity8GB DDR3
SSD512GB
HDDNo
Screen Size12.1"
TouchscreenYes

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

What video interfaces does the HD port support and what resolution does it cap at?

The HD port drives up to 1024 x 768 resolution on this panel; an external VGA port is also available for a second display.

What are the exact panel cut-out dimensions for embedded mounting?

The opening hole measures 301 x 229 mm, matching the 306.8 x 235.12 mm outer frame.

How is the operating system installed on the mSATA or M.2 drive and what step is often missed?

Boot the Windows 11 Pro installer from a USB stick, select the mSATA or M.2 2280 SSD as the target, and remember to enable the watchdog timer (255) in BIOS for 24/7 reliability.
