Silver 18.5 inch industrial all-in-one PC with capacitive touchscreen and fanless aluminium chassis

partaker

Partaker A12-PA-190TPC-CE6B(I56) 18.5" industrial all-in-one PC i5-6th 8GB 256GB

SKU CH-ZVWJ-6C7KQ

18.5" IP65-rated fanless panel PC with 10-point capacitive touch, Intel Core i5 6th Gen, 8GB DDR3 and 256GB SSD for 24/7 industrial use

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 6th Gen
  • CPU Name2.00GHz
  • GPU/VGA TypeIntel Iris Graphics 540

GPU Intel Iris Graphics 540

Memory 8GB DDR3

  • 4GB DDR3
  • 8GB DDR3

SSD 256GB

HDD None

Přeškrtnuté varianty existují, ale zde nejsou skladem.

  • IP65 front panel resists dust and water jets
  • 10-point capacitive touch enables precise multi-finger control
  • Fanless aluminium chassis runs silently with passive cooling
  • 12 V DC input suits industrial power environments
  • 256 GB SSD and 8 GB DDR3 deliver responsive performance

Industrial 18.5" Panel PC

The Partaker A12-PA-190TPC-CE6B(I56) is an 18.5 inch fanless all-in-one computer with a 10-point projected capacitive touchscreen. It runs on an Intel Core i5 6th Gen processor at 2.00GHz with Intel Iris Graphics 540, 8GB DDR3L memory and a 256GB mSATA SSD. The front panel carries IP65 protection and the aluminium chassis enables silent 7 x 24 hour operation in industrial environments.

Suited for embedded automation.

This unit fits kiosk, HMI and machine-control roles that need a sealed front panel, wide 100-240V AC input and legacy COM ports. The single SODIMM slot is factory-limited to 8GB DDR3L, so buyers who need more than 8GB RAM must choose a different architecture. The 1366 x 768 display and 250 cd/m2 brightness serve indoor control cabinets, not high-ambient-light or outdoor signage.

Storage expandability decided by mSATA

The board provides one mSATA slot — occupied by the 256GB boot drive — plus one 2.5 inch SATA bay for a second SSD or HDD. No additional M.2 or PCIe storage interfaces are present, so total capacity and interface speed are bound by these two bays.

Přednosti

  • IP65 front panel resists dust and water jets
  • 10-point capacitive touch enables precise multi-finger control
  • Fanless aluminium chassis runs silently with passive cooling
  • 12 V DC input suits industrial power environments
  • 256 GB SSD and 8 GB DDR3 deliver responsive performance

Specifikace

ModelA12-PA-190TPC-CE6B(I56)-8G256G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 6th Gen
CPU Name2.00GHz
GPU/VGA TypeIntel Iris Graphics 540
Memory Capacity8GB DDR3
SSD256GB
HDDNo
Screen Size18.5"
TouchscreenYes

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

Should I pick the 8 GB DDR3L version or can I upgrade to the maximum 8 GB later?

The system ships with 8 GB DDR3L 1333/1600 in its single SODIMM slot, which is already the supported maximum.

What does the 2.00 GHz 6th-gen Core i5 deliver inside this fanless panel PC?

The Intel Core i5 6th Gen at 2.00 GHz with Intel Iris Graphics 540 runs passively cooled, providing silent 7×24 operation for industrial workloads.

Which I/O ports are on the unit and what do they limit in practice?

You get HDMI, VGA, 2×USB 3.0, 2×USB 2.0, LAN, audio in/out, 2×COM and 12 V DC; video outputs support the native 1366×768 panel resolution.
