13.3 inch industrial all-in-one PC with resistive touchscreen and fanless aluminium chassis

partaker

Partaker A3 13.3" all-in-one PC i5-1135G7 16GB DDR4 512GB SSD 1TB HDD

SKU CH-PK3X-VT180

A 13.3-inch industrial all-in-one PC with an IP65-rated resistive touchscreen, Intel Core i5-1135G7 processor, 16GB DDR4 memory, 512GB SSD and 1TB HDD storage, fanless cooling.

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 11th Gen
  • GPU/VGA TypeIntel Iris Xe Graphics
  • Memory Capacity16GB DDR4
  • SSD512GB

Memory Capacity 16GB DDR4

SSD 512GB

HDD 1TB

Přeškrtnuté varianty existují, ale zde nejsou skladem.

  • IP65 front-panel protection resists dust and water ingress
  • 5-wire resistive touchscreen rated for 35 million touches
  • Fanless aluminium chassis delivers silent 0 dB operation
  • Intel Core i5-1135G7 up to 4.20 GHz handles continuous industrial workloads
  • Dual 2.5 GbE LAN plus 2 COM ports connect legacy and modern equipment

Industrial panel PC for embedded control

The Partaker A3 is a 13.3-inch all-in-one computer built around an Intel Core i5-1135G7 processor with Intel Iris Xe graphics. It ships with Windows 11 Pro, 16GB DDR4 memory, a 512GB SSD and a 1TB HDD. The fanless aluminium chassis and IP65-rated front panel suit continuous operation in industrial cabinets or wall-mounted stations.

High-temperature 5-wire resistive touchscreen

The display uses a five-wire resistive layer rated for 35 million touches and 80±5% transmittance at 550 nm. It operates reliably from 0 to 50°C with the SSD installed, or 0 to 40°C when the mechanical hard drive is active. The 1280 x 800 TFT LED panel delivers 300 cd/m² brightness and 800:1 contrast with 70° horizontal and 55° vertical viewing angles.

Dual-drive storage with 64GB memory ceiling

The M.2 2260/2280 slot hosts the 512GB boot drive while a 2.5-inch bay holds the 1TB SATA HDD for bulk data. Two SODIMM slots support DDR4-3200 up to 64GB total, giving headroom for heavier workloads. Expansion includes M.2 Key E for WIFI6 and Key B for 5G with a SIM slot, plus dual LAN, dual COM, HDMI, VGA and four USB ports.

Přednosti

  • IP65 front-panel protection resists dust and water ingress
  • 5-wire resistive touchscreen rated for 35 million touches
  • Fanless aluminium chassis delivers silent 0 dB operation
  • Intel Core i5-1135G7 up to 4.20 GHz handles continuous industrial workloads
  • Dual 2.5 GbE LAN plus 2 COM ports connect legacy and modern equipment

Specifikace

ModelA3-PA-133TPC-CE5A(I5B)-16G512G1TB
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 11th Gen
GPU/VGA TypeIntel Iris Xe Graphics
Memory Capacity16GB DDR4
SSD512GB
HDD1TB
Screen Size13.3"
TouchscreenYes

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

How does the i5-1135G7 running up to 4.20 GHz perform inside this fanless chassis?

The aluminum alloy passive cooling keeps the processor at safe temperatures for continuous industrial workloads without any moving parts or noise.

What does the dual LAN and COM port layout actually let me connect on the shop floor?

Two Gigabit Ethernet links give redundant network paths, while two serial ports connect legacy PLCs, barcode scanners or HMIs directly.

What cut-out size and depth do I need to embed this 13.3" unit in a cabinet?

The panel requires a 326 x 232 mm opening and 52.5 mm of clearance behind the front bezel for the embedded buckle kit.
