21.5 inch gray industrial all-in-one PC with flat resistive touchscreen

partaker

partaker A30 21.5" all-in-one PC i3-5005U 8GB 512GB SSD

SKU CH-4WWR-WQPMJ

21.5" IP65-rated resistive touch all-in-one with fanless cooling, dual LAN, dual COM, four USB 3.0 ports, 8 GB DDR3L and 512 GB SSD running Windows 11 Pro

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i3 5th Gen
  • CPU NameIntel Core i3-5005U

A30 21.5" Resistive I3 5005U 8GB RAM / 512GB SSD

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium cooling runs silently from -20 °C to 60 °C
  • Dual Gigabit LAN plus four USB 3.0 ports for industrial connectivity
  • Resistive touch rated beyond 50 million touches for long HMI life
  • 5" Full HD display with 250 cd/m² brightness and full viewing angle

Industrial 21.5" all-in-one with resistive touch

The Partaker A30 combines a 21.5 inch full HD display with an Intel Core i3-5005U processor, 8GB of DDR3L memory and a 512GB SATA SSD in a single IP65-rated front panel. It ships with Windows 11 Pro and is built for factory automation, HMI stations and embedded kiosk deployments where dust, moisture and wide temperature swings are normal.

Fanless aluminium chassis runs -20°C to 60°C

Passive cooling eliminates moving parts, so the system operates silently without dust ingestion or fan failure risk. The aluminium alloy body dissipates heat from the 5th generation dual-core CPU during 24/7 workloads, while the SSD storage maintains performance across the full industrial temperature range without throttling.

Dual COM ports, dual LAN and four USB 3.0 on a 12V

Two RS232/485 serial ports connect legacy PLCs and sensors, while dual Realtek Gigabit LAN enables segregated networks. Four USB 3.0 ports support peripherals, and two Mini PCIe slots with a SIM holder allow wireless expansion. The unit accepts standard 12V DC with optional 9-36V wide-range input, and mounting clips support panel, wall, desktop or cantilever installation.

Přednosti

  • IP65 front panel resists dust and water ingress
  • Fanless aluminium cooling runs silently from -20 °C to 60 °C
  • Dual Gigabit LAN plus four USB 3.0 ports for industrial connectivity
  • Resistive touch rated beyond 50 million touches for long HMI life
  • 5" Full HD display with 250 cd/m² brightness and full viewing angle

Specifikace

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 11 Pro
CPU TypeIntel Core i3 5th Gen
CPU NameIntel Core i3-5005U
Screen Size21.5"
Screen TypeMulti-Touch Screen

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

Does the fanless aluminium cooling stay quiet and cool when the i3-5005U runs 24/7?

The passive aluminium design has no moving parts, so it runs silently; it is rated for continuous operation from -20 °C to 60 °C with an SSD installed.

Which cables and mounts do I need on hand before installing the A30?

The box includes the panel PC, AC-to-12 V power supply, power cord and four embedded mounting clips; you only add your own network cables, USB peripherals and any Mini PCIe wireless modules.

Will my existing RS-485 sensors and dual-monitor setup work with the two COM ports and HDMI output?

COM1 and COM2 both support RS-232 and RS-485, and the HDMI port drives a second display at 1920×1080 alongside the built-in touchscreen.
