Small black aluminium box with fan cooling, compact industrial mini PC

partaker

partaker N7 Fan Mini PC Intel Core i3 1215U 16GB 512GB barebone mini PC

SKU CH-064A-7NB77

Fanless mini PC with an Intel Core i3 1215U, 16 GB DDR5, 512 GB SSD and three 2.5 GbE ports for industrial edge use

  • ColorBlack
  • CPU TypeIntel Core i3 12th Gen

CPU Type Intel Core i3-1215U

Group 16GB RAM / 512GB SSD

  • Fanless operation with fan-assisted cooling for silent industrial reliability
  • 12th Gen Intel Core i3 1215U six-core processor reaches 4.4 GHz turbo speed
  • Triple 2.5 GbE Intel i225-V ports enable high-speed network redundancy
  • DDR5 4800 memory support up to 32 GB for responsive multitasking
  • M.2 2280 NVME plus 2.5-inch bay and 4G/5G expansion for flexible storage

Compact fan-cooled mini PC for industrial edge

The partaker N7 is a barebone system built around an Intel Core i3 1215U processor with six cores and eight threads reaching 4.4 GHz turbo. It ships with 16 GB of DDR5 4800 memory and a 512 GB NVME drive installed. Fan cooling and an all-aluminium chassis allow continuous operation in commercial temperatures up to 40 °C or industrial ranges to 50 °C with an SSD.

Verify power input and I/O match your installation

The unit requires a DC 12 V supply; confirm your cabinet or DIN-rail power budget before ordering. Three Intel i225-V 2.5G LAN ports, two COM ports with RS232/RS485 support, four USB 3.1 ports, three HD-MI outputs and a SIM slot are exposed on the front panel. Expansion inside includes one M.2 2280 M-key slot, one M.2 3052 B-key slot for 4G/5G and one MINI-PCIE slot for Wi-Fi or BT modules.

Aluminium enclosure with VESA mount

The fan-assisted aluminium case measures 170 x 140 x 58 mm and weighs 2.5 kg, designed for VESA mounting behind displays or inside cabinets. Connectors are grouped on one face for tidy cable routing in tight enclosures. Internal drive bays accept one 2.5-inch SSD or HDD alongside the M.2 NVME slot. Buyers needing more than 32 GB RAM or additional 2.5G LAN ports should consider a larger industrial chassis.

Přednosti

  • Fanless operation with fan-assisted cooling for silent industrial reliability
  • 12th Gen Intel Core i3 1215U six-core processor reaches 4.4 GHz turbo speed
  • Triple 2.5 GbE Intel i225-V ports enable high-speed network redundancy
  • DDR5 4800 memory support up to 32 GB for responsive multitasking
  • M.2 2280 NVME plus 2.5-inch bay and 4G/5G expansion for flexible storage

Specifikace

ColorBlack
CPU TypeIntel Core i3 12th Gen

Další verze tohoto modelu

Dalších 5 v této řadě

Stejná řada, jiná paměť, chladič nebo takt — porovnejte, než se rozhodnete.

Otázky k tomuto produktu

Does the N7 come with RAM and storage installed, or do I need to add my own DDR5 SODIMM and M.2 drive?

The unit is a barebone system. It includes one DDR5 4800 SODIMM slot supporting up to 32 GB and one M.2 2280 slot for NVME storage, plus a 2.5-inch bay, but memory and drives are not included.

The listing mentions i3 1215U, i5 1235U and i7 1255U options — which one is this specific unit?

This configuration ships with the Intel Core i3 1215U processor, a six-core eight-thread CPU with a maximum turbo frequency of 4.4 GHz.

What does the 2.5 GbE rating on the three Intel i225-V ports mean for actual throughput in a typical network?

Each port can handle up to 2.5 Gbps of wired bandwidth, so the three ports together provide multiple high-speed links for industrial gateways, edge nodes or multi-WAN routing.
