Rectangular 2U rackmount unit with twelve NEMA 5-20R outlets on the front

APC

APC Smart-UPS Ultra Step-Down Transformer SRTL5KRMTF 5000 VA 208 V 120 V 2U 12x NEMA 5-20R

SKU CH-AT4P-T6ZEV

A 2U step-down transformer converts 208 V input to 120 V output for 12 NEMA 5-20R outlets with 15 A breakers

  • Input Voltage Range208 V
  • Dimensions30.5" D x 9.0" H x 23.5" W
  • Weight223.0 lbs
  • Connects 120 V gear to 208 V UPS power
  • 12 NEMA 5-20R outlets with 15 A breakers
  • Rackmount or tower install above SRTL5K UPS
  • 2U height fits dense server racks
  • 5000 VA capacity for high-load equipment

Step-Down Transformer for 5kVA UPS

The APC Smart-UPS Ultra SRTL5KRMTF converts 208 V input to 120 V output for rackmount or tower setups. It attaches above a compatible SRTL 5kW UPS to power 120 V equipment from an existing installation. The unit delivers 5000 VA capacity in a 2U form factor.

Rackmount or Tower Mounting

The chassis measures 30.5" D x 9.0" H x 23.5" W and weighs 223.0 lbs for stable rack or floor placement. Twelve NEMA 5-20R outlets are grouped with 15 A thermal circuit breakers: two banks of four sockets and two banks of two sockets. Installation requires vertical space above the UPS.

Outlet Groups with Circuit Protection

Four independent breaker groups protect connected loads from overload without shutting down the entire unit. The 120 V output feeds standard North American plugs directly from the transformer. No additional accessories or software are bundled with this model.

Punti di forza

  • Connects 120 V gear to 208 V UPS power
  • 12 NEMA 5-20R outlets with 15 A breakers
  • Rackmount or tower install above SRTL5K UPS
  • 2U height fits dense server racks
  • 5000 VA capacity for high-load equipment

Caratteristiche tecniche

BrandAPC
SeriesSmart-UPS Ultra
ModelSRTL5KRMTF Step-Down Transformer
Part NumberSRTL5KRMTF
Input Voltage Range208 V
Dimensions30.5" D x 9.0" H x 23.5" W
Weight223.0 lbs

Domande su questo articolo

What input voltage does the SRTL5KRMTF step-down transformer accept?

The unit accepts a 208 V input and delivers 120 V output to connected equipment.

What are the exact dimensions and weight for rack planning?

It measures 30.5" deep, 9.0" high and 23.5" wide, weighing 223.0 lbs.

How is the transformer mounted relative to the compatible UPS?

Install the step-down transformer above the compatible SRTL 5kW UPS in a rack or tower orientation.
