Green PCB PCIe x1 card with two USB-C and three USB-A ports on a metal bracket

ESTONE

ESTONE PCIE23A2C3.2 5-Port USB 3.2 Expansion Card

SKU CH-BA9X-H6ZED

Adds five USB 3.2 ports — three Type-A and two Type-C — through a single PCI Express slot with up to 10 Gbps bandwidth

  • TypePCI to USB Card
  • External USB Ports5x USB Ports
  • StandardUSB 3.1
  • Data Transfer RateUp to 10 Gbps
  • Operating Systems SupportedWindows 7/8/10/11
  • CompatibilityWidely Compatibility: The card is compatible with Windows 7/
  • Add five USB 3.2 ports to your desktop in one step
  • Transfer files at up to 10 Gbps with USB 3.2 Gen 2 speed
  • Works in PCIe 4.0, 3.0 and 2.0 slots from x1 to x16
  • Runs on Windows XP through 11, Mac OS 10.8.2+ and Linux
  • Each port has independent 2 A power and over-current protection

Five-port USB 3.2 add-in card

This PCI Express x1 card adds five USB 3.2 ports to a desktop: three Type-A and two Type-C. It targets builders who need more front-panel or rear I/O for external drives, peripherals and VR headsets without replacing the motherboard. The board draws power directly from the slot, so no extra cable is required.

Sustained 10 Gbps bandwidth per port

Each port can deliver up to 10 Gbps when used alone; the two Type-C and two Type-A ports share that bandwidth pool, while the bottom Type-C port keeps its own dedicated 10 Gbps lane. Real-world throughput will drop when multiple high-speed drives transfer simultaneously, and the card does not support Thunderbolt or video output.

Driver install on older Windows.

Windows 7, 8, Vista, XP and Server 2008 need the supplied Renesas/VLI driver from the included CD or a download. Windows 10, 11, Linux and macOS 10.8.2+ recognise the card automatically. The half-height bracket fits x1, x4, x8 or x16 slots, but low-profile cases may need the full-height bracket swapped.

Punti di forza

  • Add five USB 3.2 ports to your desktop in one step
  • Transfer files at up to 10 Gbps with USB 3.2 Gen 2 speed
  • Works in PCIe 4.0, 3.0 and 2.0 slots from x1 to x16
  • Runs on Windows XP through 11, Mac OS 10.8.2+ and Linux
  • Each port has independent 2 A power and over-current protection

Caratteristiche tecniche

BrandESTONE
SeriesPCIE23A2C3.2
ModelPCIE23A2C3.2
TypePCI to USB Card
External USB Ports5x USB Ports
StandardUSB 3.1
Data Transfer RateUp to 10 Gbps
Operating Systems SupportedWindows 7/8/10/11
CompatibilityWidely Compatibility: The card is compatible with Windows 7/8/10/11 (32/64 bit) and Mac OS 10.8.2 and above. The card only requires installing a driver which you can download from our CD driver, when operating on Windows 7. Note: Windows XP,/Vista/7, Server,requires driver installation, Windows 10/11 and Mac OS and Linux don't need drivers.
Specifications5 Ports PCI-E to USB 3.2 HUB PCI Express Expansion Card Adapter 10Gbps for Motherboard
You need to install the RENESAS/VLI USB3.0 driver for your computer first.
Supports PCI Express 2.0 X1 lane, can transferring up to 10Gbps.
PCI Express x1 slot card for usb expansion 5 Ports USB interface Card (2X USB-C - 3X USB-A)
Power Input: no need extral Power Connector
Power output: +/-5V / 900mA (each port)
Compatible: USB1.1/2.0/3.0/3.2
Operating Systems: Windows7/8/10(32/64bit)
?
FeaturesPCI Express x1 slot card for usb expansion 5 Ports USB interface Card (2X USB-C - 3X USB3.2)
USB3.0 Backwards compatible older USB 2.0 and 1.1 devices; Comply with PCI-e 3.0 PCIe 2.0 motherboards, Fits PCI Express x1, x4, x8 or x16 socket .Operating System Supports Windows XP/Vista/2008 Server/7/8/10,and Mac 0s (10.8.2 above) . Note: Windows XP,/Vista/7, Server,requires driver installation, Windows 10 and Mac OS 10.8.2 above don't need drivers.
transfer rates of up to 10Gbps copying HD videos, music, photos,data files between USB devices and the computer at blazing fast speeds.Note:T
Dimensions4.92 x 4.06 x 1.06 inches
Weight3.2 ounces
Package Contents1x USB 3.2 PCI-E expansion card, 1x CD driver, 1 x installation screws, and 1x user manual.

Domande su questo articolo

How much power does the ESTONE PCIE23A2C3.2 card draw when all five ports run at 10 Gbps all day?

The card draws power from the PCI Express slot with no external supply needed; each port has independent 2 A overcurrent and static protection.

What must my motherboard provide for the ESTONE PCIE23A2C3.2 to work?

A free PCI Express x1, x4, x8 or x16 slot compliant with PCIe 4.0, 3.0 or 2.0; the card fits any of those slots.

Will my USB 2.0 keyboard and mouse work on the ESTONE PCIE23A2C3.2 alongside newer drives?

Yes, the ports are backward compatible with USB 2.0 and 1.1 devices, so older peripherals work alongside 10 Gbps drives.
