Square 120 mm case fan with black frame and transparent blades, 25 mm thick, four-pin PWM connector visible

COUGAR

COUGAR MHP120 120 mm 2000 RPM HDB PWM case fan

SKU CH-9C31-0DDP7

120 mm PWM case fan spins at up to 2000 RPM, delivering 82.48 CFM airflow and 4.24 mm H2O static pressure through a hydraulic bearing with anti-vibration dampers

  • Fan Counts1 Fan
  • Fan ControllerNo Controller
  • TypeCase Fan
  • Fan Size120mm
  • Fan Thickness25mm
  • Bearing TypeHydraulic Bearing

Option 1 Pack

  • High airflow of 82.48 CFM for efficient case cooling
  • 24 mm H₂O static pressure excels on radiators and dense meshes
  • Hydraulic bearing and PWM control span 600-2000 RPM
  • Metallic-reinforced hub and shell add structural rigidity
  • Anti-vibration dampers and low-noise adaptor reduce operating noise

120 mm PWM case fan for radiators

The COUGAR MHP120 is a 120 mm case fan built around a hydraulic bearing and a four-pin PWM connector. Its metallic-reinforced motor hub and shell add structural rigidity while the supplied anti-vibration dampers reduce transmitted resonance. A 100 mm low-noise adaptor and a 300 mm extension cable are included for flexible routing.

Suited to high-static-pressure cooling.

This fan targets radiators and restrictive heatsinks where its 4.24 mm H₂O pressure rating at 2000 RPM matters. Builders who prioritise absolute quiet over airflow density should look elsewhere, as the maximum noise level reaches 41.2 dB(A). Systems without a PWM header cannot use the automatic speed curve.

Sustained output at rated voltage

At 12 VDC and 0.23 A the motor draws 2.76 W while delivering 82.48 CFM across the 600 to 2000 RPM range. The hydraulic bearing maintains consistent torque during prolonged operation and the reinforced hub resists flex under continuous load. Speed stability stays within the stated tolerance without thermal throttling.

Pluspunten

  • High airflow of 82.48 CFM for efficient case cooling
  • 24 mm H₂O static pressure excels on radiators and dense meshes
  • Hydraulic bearing and PWM control span 600-2000 RPM
  • Metallic-reinforced hub and shell add structural rigidity
  • Anti-vibration dampers and low-noise adaptor reduce operating noise

Specificaties

BrandCougar
ModelMHP120
Fan Counts1 Fan
Fan ControllerNo Controller
TypeCase Fan
Fan Size120mm
Fan Thickness25mm
Bearing TypeHydraulic Bearing
RPM600-2000 RPM +/- 200RPM
Air Flow82.48 CFM +/- 10%
Noise Level41.2 dB(A) (Max.)
Power Connector4 Pin PWM
FeaturesMetallic-reinforced Motor Hub & Shell
Extreme Cooling Fan With 2000 RPM (max)
HDB Bearing & PWM Control
Anti-vibration Damper
Air Pressure: 4.24 mm H2O±10%
Rated Voltage: 12 VDC
Rated Current: 0.23 A
Power Consumption: 2.76 W +/- 10%
Cable Length: 200 mm (With 100mm Y-cable)
Weight: 186g
Dimensions120 x 120 x 25 mm
Package Contents1 x MHP120
1 x 300mm Extension Cable
1 x 100mm Low-Noise Adaptor
Fan Screw Kit
User Manual

Andere versies van dit model

Nog 1 in dezelfde serie

Dezelfde familie, met ander geheugen, andere koeler of kloksnelheid — vergelijk voordat u beslist.

Vragen over dit artikel

Does the 4-pin PWM connector plug straight into a standard motherboard fan header?

Yes, the 4-pin PWM connector fits any standard motherboard fan header and draws 12 VDC at 0.23 A.

Will the 120 mm frame and 25 mm thickness fit the same mounting holes as my older 120 mm fans?

Yes, the 120 x 120 x 25 mm dimensions match the standard 120 mm mounting pattern used by older fans.

How can I confirm the hydraulic bearing is running within its 600-2000 RPM range after installation?

Check the RPM reading in BIOS or fan-control software; at minimum PWM it should sit near 600 RPM and at maximum PWM near 2000 RPM.
