Green circuit board with gold PCIe edge connector and two black antenna sockets

HP TXA117 WiFi 7 PCIe network card, Intel BE200, 9.3Gbps, Bluetooth 5.4

SKU CH-2HEJ-QAX83

Adds WiFi 7 and Bluetooth 5.4 to a desktop via PCIe x1, reaching 9.3 Gbps across 2.4, 5 and 6 GHz bands

  • Features9.3 gigabits_per_second, pci_express_x1, Desktop, one year w
  • Dimensions14.33in W x 12.83in H x 9.06in D
  • Disclaimernot_applicable, has_fcc_id, one year warranty
  • Ultra-fast 9.3 Gbps peak throughput powered by Intel BE200 chipset
  • Tri-band 6 GHz, 5 GHz and 2.4 GHz operation with 320 MHz channel width
  • Bluetooth 5.4 integration for low-latency peripherals and higher data rates
  • PCIe x1 interface compatible with x1, x4, x8 and x16 slots
  • Windows 10 and 11 64-bit driver support for quick setup

HP TXA117 WiFi 7 PCIe Card

The HP TXA117 adds WiFi 7 and Bluetooth 5.4 to a desktop PC through a PCI Express x1 slot. It uses the Intel BE200 chipset to deliver tri-band wireless on 2.4GHz, 5GHz and 6GHz frequencies. The card targets Windows 10 and 11 64-bit users who need higher throughput for gaming or streaming. It does not support AMD-based systems.

Thermals Noise Power

The card draws power directly from the PCI Express slot without an external connector. Passive cooling keeps operation silent under typical loads. Tri-band 320MHz channel width and 6 simultaneous streams maintain efficiency during sustained transfers. No fan or active cooling is present.

Upgrade Path

The TXA117 replaces WiFi 6E or Bluetooth 5.3 adapters when 9.3Gbps peak rate and 4K QAM modulation are required. The jump is worth it for environments with 6GHz spectrum access and compatible routers. Buyers limited to 5GHz networks or older Bluetooth peripherals will not see the full benefit.

Pluspunten

  • Ultra-fast 9.3 Gbps peak throughput powered by Intel BE200 chipset
  • Tri-band 6 GHz, 5 GHz and 2.4 GHz operation with 320 MHz channel width
  • Bluetooth 5.4 integration for low-latency peripherals and higher data rates
  • PCIe x1 interface compatible with x1, x4, x8 and x16 slots
  • Windows 10 and 11 64-bit driver support for quick setup

Specificaties

BrandHP
Part NumberTXA117
Features9.3 gigabits_per_second, pci_express_x1, Desktop, one year warranty, PD9-BE200NG
Dimensions14.33in W x 12.83in H x 9.06in D
Disclaimernot_applicable, has_fcc_id, one year warranty

Vragen over dit artikel

How do I install the HP TXA117 WiFi 7 card in a PCIe x1 slot on Windows 10 or 11 64-bit?

Insert the card into any PCIe x1, x4, x8 or x16 slot, secure the bracket screw, attach the included antennas, then download and install the latest Intel WiFi and Bluetooth drivers for Windows 10/11 64-bit from the Intel website.

What maintenance will the Intel BE200 module and antennas need over time?

The BE200NGW module has no moving parts and requires no scheduled maintenance; occasionally dust the heatsink and check that the two external antenna connectors remain finger-tight for best 6 GHz and 5 GHz signal.

At what point does the 9.3 Gbps peak rate become limited during sustained heavy transfers?

The 9.3 Gbps figure is the PHY-layer maximum using 320 MHz channels and 6 streams; real-world throughput hits the PCIe x1 single-lane ceiling and the 160–320 MHz channel availability limit first.
