Small green development board with USB-C port, two JST-PH connectors, charge LED, power button and protection chip

Pimoroni

Pimoroni LiPo Amigo Pro USB-C LiPo/LiIon Charger Development Board

SKU CH-HYT8-63EQM

A USB-C LiPo/LiIon charger board with 200mA charging current, dual JST-PH connectors for simultaneous charge and power, and built-in 4.2V battery protection

  • USB-C charging with 200 mA current
  • Dual JST-PH connectors for simultaneous charge and power
  • Built-in XB6096I2S battery protector
  • Power on/off button with status LED
  • Fully assembled and ready to use

PIM612 LiPo Amigo Pro USB-C Charger Board

The PIM612 LiPo Amigo Pro is a USB-C development board that charges single-cell LiPo or LiIon packs at up to 200 mA using an MCP73831 controller. It targets makers building portable IoT edge devices who need a compact, fully assembled charging and protection module.

Sustained charge with XB6096I2S protection

The onboard XB6096I2S protector guards the cell against over-charge, over-discharge and short-circuit conditions during continuous operation. Dual JST-PH connectors allow the board to charge the battery while simultaneously powering a 4.2 V tolerant load, and the integrated switch transitions between USB and battery sources without interruption.

Verify JST-PH wiring and 4.2 V tolerance

Confirm that your battery pack uses a two-pin JST-PH plug with correct polarity before connecting. Ensure the downstream circuit is rated for a maximum of 4.2 V, as the board does not regulate the output voltage down. The 200 mA charge current suits small cells; larger packs will charge slowly.

Pluspunten

  • USB-C charging with 200 mA current
  • Dual JST-PH connectors for simultaneous charge and power
  • Built-in XB6096I2S battery protector
  • Power on/off button with status LED
  • Fully assembled and ready to use

Specificaties

Voor dit artikel zijn nog geen specificaties gepubliceerd.

Vragen over dit artikel

How much heat or noise does the LiPo Amigo Pro produce when charging a battery at 200 mA all day?

The MCP73831 charger runs at 200 mA with no fan, so it stays silent and only warms slightly during extended charge cycles.

What must I already own to start using the LiPo Amigo Pro right away?

You need a USB-C power source and a LiPo or LiIon cell with a JST-PH plug; the board arrives fully assembled and ready to connect.

Will the extra JST-PH output on the Pro model safely power a 4.2 V tolerant device I already have while the battery charges?

Yes, the second JST-PH connector and XB6096I2S protector deliver up to 4.2 V and switch seamlessly between USB and battery power.
