Black metal four-bay M.2 NVMe adapter card with removable trays and fan switch

ICY DOCK

ICY DOCK ExpressSlot MB204MP-B 4 Bay M.2 NVMe PCIe 5.0 x16 Adapter

SKU CH-EQ1Q-9EZXG

Adds four M.2 NVMe SSDs (2230–2280) via one PCIe 5.0 x16 slot with tool-less trays and an on/off fan switch

  • Holds four M.2 NVMe drives from 30 to 80 mm
  • One PCIe 5.0 x16 slot gives up to 128 Gbps per drive
  • Tool-less trays with quick-release knobs let you swap drives fast
  • Fan on/off switch suits quiet or high-airflow builds
  • Active-Power Technology cuts power to empty bays automatically

Four-bay M.2 NVMe adapter for PCIe 5.0 x16

The ICY DOCK ExpressSlot MB204MP-B fits four M.2 NVMe SSDs ranging from 2230 to 2280 lengths into a single full-height PCIe 5.0 x16 slot. It targets builders and IT staff who need dense, removable NVMe storage without occupying multiple expansion slots. Tool-less trays and a quick-release knob allow rapid drive swaps for maintenance or tiered storage workflows. Active-Power Technology powers down empty bays automatically.

Requires PCIe bifurcation x4, x4, x4, x4

The adapter only exposes four independent x4 links when the host platform supports PCIe bifurcation set to x4, x4, x4, x4 on the x16 slot. Without this firmware setting, the motherboard will not present all four drives to the operating system. Buyers must verify their motherboard or server BIOS provides this bifurcation option before purchase. No onboard bridge or PLX switching is present to compensate for missing bifurcation.

Active cooling with fan on/off switch

A built-in fan pulls air across all four installed SSDs during sustained workloads such as database writes or video ingest. The hardware switch lets operators disable the fan when chassis airflow is sufficient or when acoustic limits apply. Active-Power Technology also cuts power to unpopulated bays, reducing thermal load during partial population. The single-slot width keeps adjacent slots free for additional expansion cards.

Prednosti

  • Holds four M.2 NVMe drives from 30 to 80 mm
  • One PCIe 5.0 x16 slot gives up to 128 Gbps per drive
  • Tool-less trays with quick-release knobs let you swap drives fast
  • Fan on/off switch suits quiet or high-airflow builds
  • Active-Power Technology cuts power to empty bays automatically

Špecifikácie

Pre tento produkt zatiaľ nie sú zverejnené žiadne špecifikácie.

Otázky k tomuto produktu

What does 128Gbps per drive mean for real-world throughput?

Each M.2 NVMe SSD can reach up to 128Gbps when the host provides a PCIe 5.0 x4 link via bifurcation, delivering full Gen 5 bandwidth to every installed drive.

How does the PCIe 5.0 x16 slot connect to four separate drives?

The adapter requires motherboard PCIe bifurcation set to x4, x4, x4, x4 so the single x16 slot splits into four independent x4 electrical links, one per drive bay.

What physical space and mounting does the card need inside the case?

It occupies one full-height single-width PCIe expansion slot and accepts M.2 modules from 30mm to 80mm (2230, 2242, 2260, 2280) in tool-less removable trays.
