Green Micro ATX motherboard with black sockets and silver heatsinks

MSI

MSI H97M-P35 Intel motherboard LGA 1150 H97 DDR3 16GB Micro ATX

SKU CH-NJGZ-DKW2J

Micro-ATX board for LGA 1150 CPUs with DDR3 up to 16 GB, one PCIe 3.0 x16 slot, six SATA ports, Realtek ALC887 audio and gigabit LAN

  • CPU Socket TypeLGA 1150
  • CPU Type4th generation Intel Core ™ i7/Core ™ i5/Core ™ i3/Pentium/C
  • ChipsetIntel H97
  • Memory StandardSupport DDR3 1066/1333/1600MHz memory
  • Maximum Memory Supported16GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 2.0 x1 slots
  • Supports 4th-gen Intel Core i7/i5/i3 on LGA 1150 socket
  • H97 chipset enables DDR3 memory up to 1600 MHz and 16 GB capacity
  • PCIe 3.0 x16 slot plus two PCIe 2.0 x1 slots for expansion cards
  • Six SATA III ports with RAID support for fast storage arrays
  • Realtek ALC887 8-channel audio and Gigabit LAN for media and networking

Socket 1150 Micro ATX board

The MSI H97M-P35 is a Micro ATX motherboard built around the Intel H97 chipset for LGA 1150 processors. It accepts 4th generation Intel Core i7, i5, i3, Pentium and Celeron CPUs. The board provides a compact foundation for office or home systems that do not need a full-size ATX layout.

Two x16 and x1 slots plus six SATA ports

A single PCIe 3.0 x16 slot handles a graphics card while two PCIe 2.0 x1 slots leave room for add-in cards such as sound or networking. Six SATA III connectors support multiple hard drives or SSDs without extra controllers. Four USB 3.0 ports and six USB 2.0 ports give plenty of peripheral connectivity.

16 GB DDR3 ceiling and 8-channel audio

Two memory slots support DDR3 at 1066, 1333 and 1600 MHz up to a total of 16 GB, which covers typical multitasking and light content creation. The Realtek ALC887 codec delivers 8-channel output compliant with Azalia 1.0. Gigabit Ethernet is provided by a Realtek 8111G controller for wired networking.

Prednosti

  • Supports 4th-gen Intel Core i7/i5/i3 on LGA 1150 socket
  • H97 chipset enables DDR3 memory up to 1600 MHz and 16 GB capacity
  • PCIe 3.0 x16 slot plus two PCIe 2.0 x1 slots for expansion cards
  • Six SATA III ports with RAID support for fast storage arrays
  • Realtek ALC887 8-channel audio and Gigabit LAN for media and networking

Špecifikácie

BrandMSI
SeriesMSI H97M-P35
ModelMSI H97M-P35
CPU Socket TypeLGA 1150
CPU Type4th generation Intel Core ™ i7/Core ™ i5/Core ™ i3/Pentium/Celeron processors with Socket 1150 architecture
ChipsetIntel H97
Memory StandardSupport DDR3 1066/1333/1600MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 2.0 x1 slots
SATA RAID6XSATA III interface
Audio ChipsetRealtek ALC887 Audio Chip
- Supports 8-channel audio output
- Compliant with Azalia 1.0 specifications
LAN Chipset1 PCI Express network port supports 10/100/1000 Fast Ethernet provided by Realtek 8111G
Onboard USB4 USB 3.0 ports (2 on the backplane, 2 built-in)
6 USB 2.0 ports (2 on the backplane, 4 built-in)

Otázky k tomuto produktu

What is the maximum DDR3 memory capacity this board can address?

The board supports up to 16GB of DDR3 memory across its available slots.

How loud does the system get when the Realtek 8111G LAN controller runs at full 1000Mbps throughput all day?

The LAN controller is a passive component and produces no audible noise; system sound will depend on the CPU cooler and case fans you install.

Which CPU cooler mounting pattern must my existing cooler use to fit the LGA 1150 socket on this board?

The socket uses the standard LGA 1150 mounting layout, so any cooler designed for that socket will attach correctly.
