Gray 15.6 inch all-in-one panel PC with resistive touchscreen and aluminum chassis

partaker

partaker A28 15.6 resistive touch AI edge system i5-4200U 16GB 512GB

SKU CH-VNEG-X0AWW

A 15.6-inch fanless industrial panel PC with a resistive touchscreen, Intel Core i5-4200U processor, 16GB DDR3 memory and a 512GB mSATA SSD.

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 4th Gen
  • CPU NameIntel Core i5-4200U

A28 15.6" Resistive I5 4200U 16GB RAM / 512GB SSD

  • 6" Full HD 1920x1080 display with 400 cd/m² brightness for clear industrial viewing
  • IP65-rated front panel resists dust and water ingress in harsh environments
  • Fanless aluminum alloy chassis ensures silent, maintenance-free operation from -20 to +60°C
  • Dual Gigabit LAN plus 2 COM, 4 USB, HDMI and dual mini PCIe slots for flexible connectivity
  • Intel Core i5-4200U with 16GB DDR3 and 512GB storage delivers reliable edge computing performance

Industrial panel PC for edge AI

The Partaker A28 is a 15.6 inch all-in-one system built around an Intel Core i5-4200U processor running up to 2.60 GHz with 16 GB of DDR3 memory and a 512 GB mSATA drive. It ships with Windows 10 Pro and targets industrial automation, kiosk or edge AI deployments that need a sealed, fanless unit. The aluminium alloy chassis and IP65-rated front panel allow mounting in dusty or wet environments where a standard PC would fail.

Verify power voltage and panel cutout before

The system accepts a standard 12 V DC input with an optional 9 to 36 V wide-range configuration that must be specified at purchase. Mounting requires a precise 385 by 234.3 mm rectangular cutout for the embedded IP65 bezel. Expansion uses two mini PCIe slots; one supports a Wi-Fi, Bluetooth or cellular module with a SIM holder, while the other is wired for Wi-Fi only. The dual COM ports are configurable as RS232 or RS485 and can be expanded to six with a custom order.

Resistive touch and dual display change daily

The default resistive touchscreen is rated for 50 million touches and works with gloves or a stylus, unlike capacitive alternatives. Dual display output via HDMI and the internal LVDS connection lets operators mirror or extend the 1920 by 1080 panel to a second monitor. Two 8 W speakers provide local audio alerts, while the watchdog timer (0 to 255 levels) and timer power-on functions enable unattended recovery after a fault or scheduled start-up.

Prednosti

  • 6" Full HD 1920x1080 display with 400 cd/m² brightness for clear industrial viewing
  • IP65-rated front panel resists dust and water ingress in harsh environments
  • Fanless aluminum alloy chassis ensures silent, maintenance-free operation from -20 to +60°C
  • Dual Gigabit LAN plus 2 COM, 4 USB, HDMI and dual mini PCIe slots for flexible connectivity
  • Intel Core i5-4200U with 16GB DDR3 and 512GB storage delivers reliable edge computing performance

Špecifikácie

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 4th Gen
CPU NameIntel Core i5-4200U
Screen Size15.6"
Screen TypeMulti-Touch Screen

Ďalšie verzie tohto modelu

Ďalších 5 v tomto rade

Rovnaký rad, iná pamäť, chladič alebo frekvencia — porovnajte pred rozhodnutím.

Otázky k tomuto produktu

What comes in the box with the Partaker A28 and what must I source separately?

The unit ships as a complete all-in-one with the 15.6 inch resistive touchscreen, Intel Core i5-4200U processor, 16GB DDR3 memory, 512GB mSATA SSD and Windows 10 Pro pre-installed. GPIO, four extra COM ports and two additional USB interfaces are listed as optional expansions not included in the standard shipment.

Which memory and storage configuration should I choose for this model?

This specific SKU is already configured with the maximum 16GB DDR3 across two slots and a 512GB mSATA drive; no further capacity options are offered for this part number.

How does the 2.60 GHz turbo frequency behave inside the fanless chassis?

The dual-core i5-4200U can reach 2.60 GHz under load, and the all-aluminium fanless design is rated for continuous operation from -20 to +60 °C, so sustained performance is maintained without throttling in industrial temperature ranges.
