15.6 inch IP65 all-in-one panel PC with projected capacitive touchscreen and fanless aluminium chassis

partaker

Partaker A6 15.6" IP65 all-in-one PC i5-8265U 8GB DDR4 256GB

SKU CH-H7XP-MZJJD

Industrial 15.6" all-in-one with IP65 front protection, 10-point capacitive touch, i5-8265U, 8GB DDR4, 256GB SSD and fanless aluminium cooling

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 8th Gen
  • GPU/VGA TypeIntel UHD Graphics
  • Memory Capacity8GB DDR4
  • SSD256GB

Memory Capacity 8GB DDR4

SSD 256GB

  • 256GB
  • 512GB
  • 1TB

HDD None

Prečrtane različice obstajajo, vendar tukaj niso na voljo.

  • IP65 front panel resists dust and water jets in harsh settings
  • 10-point capacitive touch enables precise multi-finger control on 15.6" screen
  • Fanless aluminium cooling runs silently for 24/7 industrial use
  • Intel Core i5-8265U up to 3.90 GHz handles demanding workloads reliably
  • Windows 11 Pro pre-installed reduces setup time for immediate deployment

Industrial all-in-one with IP65 front panel

The Partaker A6 is a 15.6 inch all-in-one computer built for industrial environments. Its front panel meets IP65 protection against dust and water jets. A 10-point projected capacitive touch screen provides direct input. The system suits factories, kiosks and outdoor enclosures where standard PCs would fail.

Fanless aluminium chassis with versatile I/O

Passive cooling through the aluminium alloy chassis removes moving parts and enables silent 7x24 operation. Ports include HDMI, VGA, two USB 3.0, two USB 2.0, two LAN, audio in and out, two COM and a 12 V DC input. Embedded buckle kits allow panel, wall, desktop or cantilever mounting without extra brackets.

Expandable memory and storage for long deployments

Two SODIMM slots accept DDR4-2400 modules up to 64 GB total. Storage options cover one mSATA SSD, one M.2 2280 NVME or SATA SSD and one 2.5 inch SATA drive bay. A Mini PCIe slot with SIM holder adds Wi-Fi or 4G connectivity. The platform upgrades from older sealed panels that lack modern expansion.

Poudarki

  • IP65 front panel resists dust and water jets in harsh settings
  • 10-point capacitive touch enables precise multi-finger control on 15.6" screen
  • Fanless aluminium cooling runs silently for 24/7 industrial use
  • Intel Core i5-8265U up to 3.90 GHz handles demanding workloads reliably
  • Windows 11 Pro pre-installed reduces setup time for immediate deployment

Specifikacije

ModelA6-PA-156TPC-CE6A(I58)-8G256G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 8th Gen
GPU/VGA TypeIntel UHD Graphics
Memory Capacity8GB DDR4
SSD256GB
HDDNo
Screen Size15.6"
TouchscreenYes

Druge različice tega modela

še 5 v isti paleti

Ista družina, različen pomnilnik, hladilnik ali takt — primerjajte, preden se odločite.

Vprašanja o tem izdelku

Does the HDMI port on this A6 panel PC support 4K output or is it limited to 1920 x 1080?

The integrated Intel UHD Graphics can drive higher resolutions over HDMI, but the built-in 15.6-inch panel is fixed at 1920 x 1080, so external displays will be capped by the GPU rather than the internal screen.

What are the exact cut-out dimensions required for the embedded mounting buckles on this unit?

The opening hole measures 386.5 x 236 mm, matching the 392.6 x 241.7 mm outer dimensions with a 54.5 mm depth for flush panel integration.

Is the memory installed in a single 8 GB stick or dual-channel, and how do I add more without breaking the IP65 seal?

The board has two SODIMM DDR4-2400 slots supporting up to 64 GB; upgrades are done through the rear service cover, leaving the front IP65 seal untouched.
