Silver 1U rackmount server chassis with four front drive bays

ASRock Rack

ASRock Rack 1U4L4E-GENOA/2T 1U barebone server

SKU CH-BY7Q-6SW2F MPN 1U4L4E-GENOA/2T

1U rackmount barebone supporting AMD EPYC 9004 processors with eight DDR5 slots, four 2.5-inch NVMe/SATA bays, four 3.5-inch SATA bays, dual 10-gigabit LAN and a 750-watt 80-PLUS Platinum power supply

  • Form Factor1U Rackmount
  • WorkloadGeneral Purpose Server
  • CPU TypeSupports AMD EPYC 9004 (with AMD 3D V-Cache Technology) and
  • CPU SocketSocket SP5
  • Installed CPUNo CPU Installed
  • Max Processors1
  • Supports AMD EPYC 9004 series processors on Socket SP5
  • Eight DDR5 4800 RDIMM slots up to 96 GB per DIMM
  • Four hot-swap 2.5" NVMe PCIe5.0 x4 or SATA bays
  • Four hot-swap 3.5" SATA drive bays for capacity
  • Dual 10 Gigabit Ethernet via Intel X550-AT2 controller

1U barebone with SP5 socket

The ASRock Rack 1U4L4E-GENOA/2T is a 1U rackmount barebone server designed for general-purpose workloads. It accepts a single AMD EPYC 9004 series processor in an SP5 socket and provides eight 288-pin DDR5 4800 memory slots. No CPU or memory is installed, so the builder supplies both to match the target application.

Suits storage-dense single-socket builds

This chassis fits four hot-swap 2.5-inch bays that each take NVMe PCIe 5.0 x4 or SATA drives, plus four hot-swap 3.5-inch SATA bays. Two M.2 M-key slots add PCIe 4.0 x4 capacity. Builders needing more than one processor socket or more than eight DIMM slots should look at a different platform.

Sustained load on Platinum power

A redundant 1+1 750 W 80-PLUS Platinum power supply feeds the system during continuous operation. The Aspeed AST2600 with 512 MB DDR4 handles remote management without loading the main CPU. Dual 10 GbE ports from an Intel X550-AT2 controller maintain network throughput under prolonged traffic.

I korthet

  • Supports AMD EPYC 9004 series processors on Socket SP5
  • Eight DDR5 4800 RDIMM slots up to 96 GB per DIMM
  • Four hot-swap 2.5" NVMe PCIe5.0 x4 or SATA bays
  • Four hot-swap 3.5" SATA drive bays for capacity
  • Dual 10 Gigabit Ethernet via Intel X550-AT2 controller

Specifikationer

BrandASRock Rack
Model1U4L4E-GENOA/2T
Form Factor1U Rackmount
WorkloadGeneral Purpose Server
CPU TypeSupports AMD EPYC 9004 (with AMD 3D V-Cache Technology) and 97x4 series processors
CPU SocketSocket SP5
Installed CPUNo CPU Installed
Max Processors1
Memory Slots8 x 288Pin
Installed Memory SizeNo Memory Installed
Max Memory SupportedMax. Capacity per DIMM
- RDIMM: 96GB (2R)
- RDIMM-3DS: 512GB (2S8Rx4)
Memory Type SupportedDDR5 4800
Installed HDDNo Storage Installed
M.22 M-key (PCIe5.0 x4); support 2280/2260/2242/2230 form factor
GPU/VPUAspeed AST2600
Video Memory512MB DDR4
PCI ExpressRear: 1 FHHL PCIe5.0 x16 via RB1UX16R_G5
First LANIntel X550-AT2
Max. LAN SpeedDual 10 Gigabit
Hot-Swap Bays4 hot-swap 2.5" NVMe (PCIe5.0 x4)/SATA drive bays
4 hot-swap 3.5" SATA drive bays
ButtonsPower button w/ LED, ID button w/ LED, System reset
LEDsHDD Activity, LAN 1/2, System Event
Front USB2 x USB 3.2 Gen 1
VGA1
Rear USB2 x USB 3.2 Gen 1
RJ452 x RJ45 (10GbE)
1 x dedicated IPMI
Max. Power1+1 Slim PSU, 750W, 80-PLUS Platinum
BIOS FeaturesBIOS Type: AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM
BIOS Features: ASRock Rack Instant Flash, ACPI 6.4 and above compliance wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP)
Fans6 PWM Easy-swap 40x56 mm fans
Hardware MonitorTemperature: CPU, MB, TR1 Temperature sensing
Fan:
- CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage: VCORE,VCCSA,VCCM,3V, 5V, 12V, +BAT, 3VSB, 5VSB,VCCIO,+2.5V_VPP
TemperatureOperation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C
HumidityNon operation humidity: 20% ~ 90% ( Non condensing)
Dimensions1.7" x 17.2" x 26.6"
Fraktvikt18.80 kg
Paketstorlek980 × 630 × 220 mm

Frågor om den här produkten

Which AMD EPYC 9004 series processor and DDR5 4800 RDIMMs must I supply to complete this barebone?

Choose a single SP5 (LGA 6096) EPYC 9004 or 97x4 CPU and populate up to eight 288-pin DDR5 4800 RDIMM slots, each supporting up to 96 GB per DIMM or 512 GB per 3DS DIMM.

Can I keep using my existing 2.5" U.3 NVMe and 3.5" SATA drives in the hot-swap bays?

Yes, the four 2.5" bays accept NVMe (PCIe 5.0 x4) or SATA drives, and the four 3.5" bays accept SATA drives, so current U.3 NVMe and 3.5" SATA media will work.

How do I confirm the system is operating correctly after installing the CPU, memory and drives?

The Aspeed AST2600 BMC with 512 MB DDR4 provides IPMI remote console and sensor monitoring, while the Intel X550-AT2 dual 10 GbE ports show link status for network verification.
