Black 14-inch all-in-one panel PC with flat IP65 touchscreen and fanless aluminium chassis

partaker

Partaker Z10 all-in-one PC 14" i5-8265U 16GB 512GB

SKU CH-1FM8-SBNWG

A 14-inch fanless all-in-one with an IP65-rated 10-point touchscreen, Intel Core i5-8265U, 16GB DDR4, 512GB SSD and Windows 11 Pro for industrial use

  • Form FactorAll-in-One
  • ColorBlack
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 8th Gen
  • CPU NameIntel Core i5-8265U
  • GPU/VGA TypeIntel UHD Graphics

CPU Type Intel Core i5 8th Gen

CPU Name Intel Core i5-8265U

GPU Intel UHD Graphics

Memory 16GB DDR4

SSD 512GB

Genomstrukna varianter finns, men är inte i lager här.

  • IP65 front protection withstands dust and water jets in harsh settings
  • Fanless aluminium cooling runs silently from 0 to 50 °C
  • 10-point capacitive touch rated for 200 million touches
  • Triple storage bays (mSATA, M.2, 2.5") expand to 64 GB RAM
  • Dual LAN, dual COM, HDMI, VGA and four USB ports for industrial I/O

Industrial 14-inch panel PC

The Partaker Z10 is a fanless all-in-one computer with an Intel Core i5-8265U processor, 16GB of DDR4-2400 memory and a 512GB SSD. It runs Windows 11 Pro on a 14-inch TFT LED display with 10-point projected capacitive touch. The aluminium chassis meets IP65 front-panel protection and operates from 0 to 50°C with an SSD installed. It is built for embedded, wall-mounted or desktop use in industrial and commercial environments.

Check mounting cut-out and I/O needs

The unit requires a 340.3 x 225.3 mm panel opening for embedded installation and measures 346.3 x 231.3 x 42.7 mm overall. Verify that 12V DC power is available and that the two LAN ports, HDMI, VGA, two USB 3.0, two USB 2.0, audio in/out and two COM ports match your peripheral requirements. A Mini PCIe slot with a SIM socket is present for optional WiFi or 4G expansion. The screen resolution is 1600 x 900 with 200 cd/m² brightness.

Bundled accessories enable immediate deployment

The package includes the panel PC, a 100-240V AC to 12V DC power adapter and a power cord so the system can be powered straight away. Embedded mounting hardware is also supplied, allowing installation without sourcing separate brackets. Windows 11 Pro is pre-installed in English and the platform is compatible with Ubuntu or Linux if an alternative OS is preferred. The CCC certification confirms compliance for the supplied configuration.

I korthet

  • IP65 front protection withstands dust and water jets in harsh settings
  • Fanless aluminium cooling runs silently from 0 to 50 °C
  • 10-point capacitive touch rated for 200 million touches
  • Triple storage bays (mSATA, M.2, 2.5") expand to 64 GB RAM
  • Dual LAN, dual COM, HDMI, VGA and four USB ports for industrial I/O

Specifikationer

ModelZ10-I5 8265U-16G512G
Form FactorAll-in-One
ColorBlack
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 8th Gen
CPU NameIntel Core i5-8265U
GPU/VGA TypeIntel UHD Graphics
Memory Capacity16GB DDR4
SSD512GB
HDDNo
Screen Size14"
TouchscreenYes

Andra versioner av den här modellen

5 till i samma serie

Samma familj, men olika minne, kylning eller klockfrekvens — jämför innan du bestämmer dig.

Frågor om den här produkten

Does the box contain Wi-Fi antennas or a 4G module, or must they be purchased separately?

The package includes the panel PC, power supply, power cord and embedded mounting kit. Wi-Fi or 4G modules use the mini PCIe slot with SIM slot and are not included.

Should I choose the mSATA, M.2 NVMe or 2.5" bay for the 512 GB SSD?

The 512 GB SSD ships pre-installed in one of the three bays — mSATA, M.2 2280 NVMe/SATA or 2.5" SATA — leaving the other two bays free for future expansion.

What does the IP65 rating mean for daily use on a factory floor?

The front panel is sealed against dust and low-pressure water jets, the fanless aluminum chassis runs 0-50 °C with SSD, and the 10-point capacitive touchscreen is rated for 200 million touches.
