Black 14-inch fanless all-in-one panel PC with IP65 touchscreen

partaker

Partaker Z10 all-in-one PC Core i5-8265U 8GB 128GB 14

SKU CH-YK1G-WFFP7

A 14-inch IP65-rated all-in-one with a fanless aluminium chassis, 10-point capacitive touchscreen, Core i5-8265U, 8GB DDR4, 128GB SSD, Windows 11 Pro, dual LAN, dual COM, HDMI, VGA.

  • Form FactorAll-in-One
  • ColorBlack
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 8th Gen
  • CPU NameIntel Core i5-8265U
  • GPU/VGA TypeIntel UHD Graphics

CPU Type Intel Core i5 8th Gen

CPU Name Intel Core i5-8265U

GPU Intel UHD Graphics

Memory 8GB DDR4

  • 16GB DDR4
  • 32GB DDR4
  • 64GB DDR4
  • 8GB DDR4

SSD 128GB

Genomstrukna varianter finns, men är inte i lager här.

  • Fanless aluminium chassis runs 0–50°C for harsh environments
  • IP65 front panel resists dust and water jets in industrial use
  • 10-point capacitive touchscreen rated for 200 million touches
  • Triple storage with mSATA, M.2 2280 and 2.5″ SATA bays
  • Dual LAN, HDMI, VGA, four USB and two COM ports connect legacy gear

Industrial 14-inch panel PC

The Partaker Z10 is a fanless all-in-one computer built around an Intel Core i5-8265U processor, 8 GB of DDR4-2400 memory and a 128 GB SSD. Its front panel meets IP65 protection and carries a 10-point projected capacitive touchscreen rated for 200 million touches. The unit runs Windows 11 Pro and operates from 0 to 50 °C with solid-state storage.

Upgrade from legacy panel PCs

It replaces older fan-cooled or lower-IP-rated terminals that cannot withstand dust, water jets or wide temperature swings. The jump is worthwhile when an application needs silent aluminium cooling, triple storage bays (mSATA, M.2 2280 NVMe/SATA, 2.5" SATA) and dual LAN plus dual COM ports for industrial I/O. Buyers who need more than 64 GB of RAM or a larger display diagonal should look elsewhere.

Limits of the 14-inch 1600×900 panel

The 1600×900 resolution and 200 cd/m² brightness suit close-range HMI work but restrict fine-detail viewing or bright ambient-light use. Viewing angles are 45° left/right, 15° up and 35° down, so off-axis operators lose contrast quickly. Video output over HDMI or VGA can drive a second monitor, yet the embedded panel itself remains the primary interface constraint.

I korthet

  • Fanless aluminium chassis runs 0–50°C for harsh environments
  • IP65 front panel resists dust and water jets in industrial use
  • 10-point capacitive touchscreen rated for 200 million touches
  • Triple storage with mSATA, M.2 2280 and 2.5″ SATA bays
  • Dual LAN, HDMI, VGA, four USB and two COM ports connect legacy gear

Specifikationer

ModelZ10-I5 8265U-8G128G
Form FactorAll-in-One
ColorBlack
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 8th Gen
CPU NameIntel Core i5-8265U
GPU/VGA TypeIntel UHD Graphics
Memory Capacity8GB DDR4
SSD128GB
HDDNo
Screen Size14"
TouchscreenYes

Andra versioner av den här modellen

5 till i samma serie

Samma familj, men olika minne, kylning eller klockfrekvens — jämför innan du bestämmer dig.

Frågor om den här produkten

What are the cut-out dimensions for embedded mounting of the Z10 panel PC?

The embedded opening hole measures 340.3 x 225.3 mm, matching the 346.3 x 231.3 x 42.7 mm unit dimensions.

How is the 12 V DC power connected, and what mistake should be avoided?

Use the included 100-240 V AC to 12 V DC adapter; do not apply raw AC mains directly to the DC jack.

Which storage slots are available for future SSD or HDD upgrades?

One mSATA, one M.2 2280 NVMe/SATA, and one 2.5" SATA bay support additional drives.
